3A大电流总线稳压IC UTC UR5516B
| 价 格： | 1.08 |
| 应用范围 | 电源 | 品牌/商标 | UTC(台湾友顺） |
| 型号/规格 | UR5516B | 铁心形状 | IC |
| 冷却形式 | 充气式 |
3A BUS TERMINATION
REGULATOR
DESCRIPTION
The UTC UR5516B is a low cost linear regulator designed to
provide a desired output voltage or termination voltage for various
applications by converting voltage supplies ranging from 1V to
6.0V. The desired output voltage could be programmable by two
external voltage divider resistors.
The UR5516B is capable of sourcing or sinking up to 2A of
current while regulating an output VOUT voltage to within 2%
(DDR-I), 3% (DDR-II) or less.
The UR5516B provides low profile 8-pin SOIC package to save
system space.
FEATURES
* Provide bi-direction current
- Sourcing or sinking current up to 3A
* 1.25V/0.9V output for DDR I/II applications
* Fast transient response
* High output accuracy
- ±20mv over load, VOUT offset and temperature
* Adjustable output voltage by external resistors
* Current-limit protection
* On-chip thermal shutdown
* Shutdown for standby or suspend mode
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 宋哲
- 电话：755-29743120
- 传真：755-29743120
- 手机：
- QQ ：
电源复位IC UTC 8118 8120 8122 8125 8122 8145
信息内容：品牌/商标 UTC(台湾友顺） 型号/规格 81XX 批号 10 封装 SOT-23,SOT-25,SOT-89,TO-92 营销方式 现货 产品性质 热销 处理信号 模拟信号 制作工艺 半导体集成 类型 复位IC POWER RESET IC DESCRIPTIONThe function of UTC 81XX is to accurately reset system afterdetecting the supply voltage at the time of switching power on andinstantaneous power off in various CPU and other logic systems.Further, this IC, with its super low consumption current and highprecision voltage detection capacity, UTC 81XX is the most suitedas a voltage check circuit for a number of products which usebatteries. FEATURES*High precision voltage detection. (VSS±3% max)*low current consumption.(ICCH=5&m...
现货供160V/15W贴片三级管 2SC4027
信息内容：品牌/商标 UTC(台湾友顺） 型号/规格 2SC4027 应用范围 功率 结构 面接触型 封装形式 TO-252/TO251 封装材料 金属封装 集电极允许电流ICM 1.5（A） 集电极耗散功率PCM 15（W） 营销方式 代理 产品性质 热销 1，UTC高品质三极管，可直接替代三洋同等型号。2，大批量现货供应！为您完全抛弃找货的烦恼和怕假货的痛苦！3，可免费提供试样！全国范围支持支付宝（半月内因质量问题可退货），珠三角支持快递代收。HIGH-VOLTAGE SWITCHINGAPPLICATIONSFEATURES* High voltage and large current capacity.* Fast switching time. ABSOLUTE MAXIMUM RATING (Ta=25°C)PARAMETER SYMBOL RATINGS UNITCollector to Base Voltage VCBO 180 VCollector to Emitter Voltage VCEO 160 VEmitter to Base Voltage V...
