现货BC372 原装MOT TO-92 高频三极管
| 价 格： | 0.99 |
| 品牌/商标 | MOT | 型号/规格 | BC372 |
| 封装 | TO-92 | 批号 | 95+ |
| 类型 | 射频IC |
dzsc/18/5168/18516840.jpg
High voltage Darlington Transistors
1 Publication Order Number:
BC372/D
NPN Silicon
Features
• Pb−Free Packages are Available*
MAXIMUM RATINGS
Rating Symbol Value Unit
Collector−Emitter Voltage
BC372
BC373
VCEO
100
80
Vdc
Collector−Base Voltage
BC372
BC373
VCES
100
80
Vdc
Emitter−Base Voltage VEBO 12 Vdc
Collector Current − Continuous IC 1.0 Adc
Total Power Dissipation @ TA = 25°C
Derate above TA = 25°C
PD 625
5.0
mW
mW/°C
Total Power Dissipation @ TA = 25°C
Derate above TA = 25°C
PD 1.5
12
W
mW/°C
Operating and Storage Junction
Temperature Range
TJ, Tstg −55 to +150 °C
THERMAL CHARACTERISTICS
Characteristic Symbol Max Unit
Thermal Resistance, Junction−to−Ambient R JA 200 °C/W
Thermal Resistance, Junction−to−Case R JC 83.3 °C/W
Maximum ratings are those values beyond which device damage can occur.
Maximum ratings applied to the device are individual stress limit values (not
normal operating conditions) and are not valid simultaneously. If these limits are
exceeded, device functional operation is not implied, damage may occur and
reliability may be affected.
*For additional information on our Pb−Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
Device Package Shipping†
ORDERING INFORMATION
BC372 TO−92 5000 Units / Bulk
BC37x = Device Code
x = 2 or 3
A = Assembly Location
Y = Year
WW = Work Week
= Pb−Free Package
MARKING
DIAGRAM
TO−92
CASE 29
STYLE 1 1 2
3
BC373 TO−92 5000 Units / Bulk
BC372G TO−92
(Pb−Free)
5000 Units / Bulk
BC373G TO−92
(Pb−Free)
5000 Units / Bulk
(Note: Microdot may be in either location)
http://onsemi.com
BC
37x
AYWW
BC373RL1 TO−92 2000 / Tape & Reel
BC373ZL1 TO−92 2000 / Ammo Pack
BC373RL1G TO−92
(Pb−Free)
2000 / Tape & Reel
BC373ZL1G TO−92
(Pb−Free)
2000 / Ammo Pack
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
COLLECTOR 3
BASE
2
EMITTER 1
