降压型LED恒流驱动器芯片(高电压型) XL8004
| 价 格： | 面议 | |
| 型号/规格： | XL8004 | |
| 品牌/商标： | XLSEMI |
Features
n Wide 24V to 80V Input Voltage Range
n 0.2V current sense voltage reference.
n Directly drive 3~8 series LED.
n Excellent line and load regulation.
n High efficiency up to 96%.
n Internal optimize power HV-MOSFET.
n Built in thermal shutdown function.
n Built in UVLO function.
n Built in current limiting function.
n Built in LED open & short protection.
n Built in soft-start circuit.
n Available in TO252-5L package.
Applications
n EBIKE LED Lighting
n LED Lighting & LED LAMP
n General purpose lighting
General Description
The XL8004 is a monolithic high voltage
switching regulator with PFM that is
specifically designed to operate from a
24V~80V DC supply.
The XL8004 is a high efficiency LED driver
switching regulator. The LED string is driven
at DC constant current rather than constant
voltage, thus providing constant current
output and enhanced reliability.
Figure1. Package Type of XL8004
| 降压型LED恒流驱动器芯片(高电压型) | ||||||
| XL8002 | 12V ~ 80V | 1~18 LED串联 | 1A | PFM | Adj (0.1V) | TO263-5L |
| XL8003 | 24V ~ 80V | 3~8 LED串联 | 0.5A | PFM | Adj (0.2V) | SOP8L |
| XL8004 | 24V ~ 80V | 3~14 LED串联 | 1A | PFM | Adj (0.2V) | TO252-5L |
