降压型LED恒流驱动器芯片(高电压型) XL8002
| 价 格： | 面议 | |
| 型号/规格： | XL8002 | |
| 品牌/商标： | XLSEMI |
Features
n Operation Voltage DC 12V~80V.
n 0.1V current sense voltage reference.
n Directly drive 1~18 Series 1W/3W LED.
n Excellent line and load regulation.
n Internal Optimize Power HV-MOSFET.
n Built in Thermal Shutdown Function.
n Built in Current Limiting Function.
n Built in Soft-Start Circuit.
n Available in TO263-5L package.
n Up to 98% efficiency.
Applications
n LED Lighting & LED LAMP
n General purpose LED lighting
General Description
The XL8002 is a monolithic high voltage
switching regulator with PFM that is
specifically designed to operate from a
12V~80V DC power supply.
The XL8002 is a high efficiency LED driver
switching regulator. The LED string is driven
at DC constant current rather than constant
voltage, thus providing constant light output
and enhanced reliability.
Figure1. Package Type of XL8002
| 降压型LED恒流驱动器芯片(高电压型) | ||||||
| XL8002 | 12V ~ 80V | 1~18 LED串联 | 1A | PFM | Adj (0.1V) | TO263-5L |
| XL8003 | 24V ~ 80V | 3~8 LED串联 | 0.5A | PFM | Adj (0.2V) | SOP8L |
| XL8004 | 24V ~ 80V | 3~14 LED串联 | 1A | PFM | Adj (0.2V) | TO252-5L |
