供应19.2M/26M3225VCTCXO温补晶振
| 价 格： | 面议 | |
| 型号/规格： | NT3225SA | |
| 品牌/商标： | NDK | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 贴片式 | |
| 主要用途： | |
NT3225SA (for Mobile Communications)
Features
- Supports low power supply voltage. (Supports DC +2.4 V±0.1 V to +3.4 V±5 %.)
- Ultra-compact and light with a height, cubic volume, and weight of Max. 1.0 mm, 0.007 cm3, and 0.024g, respectively.
- With an AFC (Automatic Frequency Control) function.
- Low power consumption.
- A surface-mount crystal oscillator. (Reflow soldering is possible.)
- Lead-free. Meets the requirements for re-flow profiling using lead-free solder.
dzsc/17/6118/17611882.jpg
- dzsc/17/6118/17611882.gif
- dzsc/17/6118/17611882.gif
Specifications
Dimensions
dzsc/17/6118/17611882.jpg
