供应MP1002S贴片二极管
| 价 格： | 面议 | |
| 型号/规格： | MP1002S | |
| 品牌/商标： | 搏扬 | |
| 封装形式： | 贴片 | |
| 环保类别： | 普通型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 散装 | |
| 功率特性： | | |
| 频率特性： | | |
| 整流电流： | | |
| 反向击穿电流： | |
|
BRIDGE RECTIFIERS dzsc/17/2311/17231129.gif 2503 MP10S.pdf | ||||||||
| TYPE |
Maximum Recurrent |
Maximum Average Forward Rectified Current IO A |
MaximumPeak Forward |
Maximum |
Maximum Forward Voltage |
Maximum Forward Voltage |
||
| MP10005S | 50 | 10.0 | 200 | 10.0 | 5.0 | 1.0 | ||
| MP1001S | 100 | 10.0 | 200 | 10.0 | 5.0 | 1.0 | ||
| MP1002S | 200 | 10.0 | 200 | 10.0 | 5.0 | 1.0 | ||
| MP1004S | 400 | 10.0 | 200 | 10.0 | 5.0 | 1.0 | ||
| MP1006S | 600 | 10.0 | 200 | 10.0 | 5.0 | 1.0 | ||
| MP1008S | 800 | 10.0 | 200 | 10.0 | 5.0 | 1.0 | ||
| MP1010S | 1000 | 10.0 | 200 | 10.0 | 5.0 | 1.0 | ||
- 所属城市：广东 广州
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周建忠 先生
- 电话：0020-81859010
- 传真：0020-81920559
- 手机：13802747878
- QQ ：
供应50.0AMPERES/ KBPC50XW贴片二极管
信息内容：BRIDGE RECTIFIERS dzsc/17/2311/17231130.gif 2402 KBPC50W.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV KBPC50005W 50 50.0 500 10.0 25.0 1.1 KBPC5001W 100 50.0 500 10.0 25.0 1.1 KBPC5002W 200 50.0 500 10.0 25.0 1.1 KBPC5004W 400 50.0 500 10.0 25.0 1.1 KBPC5006W 600 50.0 500 10.0 25.0 1.1 KBPC5008W 800 50.0 500 10.0 25.0 1.1 KBPC5010W 1000 50.0 500 10.0 25.0 1.1
供应MP50005W贴片二极管
信息内容：BRIDGE RECTIFIERS dzsc/17/2311/17231131.gif 2902 MP50W.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV MP50005W 50 50.0 500 10.0 25.0 1.1 MP5001W 100 50.0 500 10.0 25.0 1.1 MP5002W 200 50.0 500 10.0 25.0 1.1 MP5004W 400 50.0 500 10.0 25.0 1.1 MP5006W 600 50.0 500 10.0 25.0 1.1 MP5008W 800 50.0 500 10.0 25.0 1.1 MP5010W 1000 50.0 500 10.0 25.0 1.1
