供应0.8AMPERES/ MBXS贴片二极管
| 价 格： | 面议 | |
| 型号/规格： | 0.8AMPERES/ MBXS | |
| 品牌/商标： | 搏扬 | |
| 封装形式： | 贴片 | |
| 环保类别： | 普通型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 散装 | |
| 功率特性： | | |
| 频率特性： | | |
| 整流电流： | | |
| 反向击穿电流： | |
|
BRIDGE RECTIFIERS dzsc/17/2311/17231107.gif 1201 MB0XS.pdf | ||||||||
| TYPE |
Maximum Recurrent |
Maximum Average Forward Rectified Current IO A |
MaximumPeak Forward |
Maximum |
Maximum Forward Voltage |
Maximum Forward Voltage |
||
| MB05S | 50 | 0.8 | 40 | 5.0 | 0.8 | 1.1 | ||
| MB1S | 100 | 0.8 | 40 | 5.0 | 0.8 | 1.1 | ||
| MB2S | 200 | 0.8 | 40 | 5.0 | 0.8 | 1.1 | ||
| MB4S | 400 | 0.8 | 40 | 5.0 | 0.8 | 1.1 | ||
| MB6S | 600 | 0.8 | 40 | 5.0 | 0.8 | 1.1 | ||
| MB8S | 800 | 0.8 | 40 | 5.0 | 0.8 | 1.1 | ||
| MB10S | 1000 | 0.8 | 40 | 5.0 | 0.8 | 1.1 | ||
- 所属城市：广东 广州
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周建忠 先生
- 电话：0020-81859010
- 传真：0020-81920559
- 手机：13802747878
- QQ ：
供应4.0AMPERES/ KBL4X贴片二极管
信息内容：BRIDGE RECTIFIERS dzsc/17/2311/17231109.gif 1502 KBL4X.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV KBL4005 50 4.0 150 10.0 4.0 1.0 KBL401 100 4.0 150 10.0 4.0 1.0 KBL402 200 4.0 150 10.0 4.0 1.0 KBL404 400 4.0 150 10.0 4.0 1.0 KBL406 600 4.0 150 10.0 4.0 1.0 KBL408 800 4.0 150 10.0 4.0 1.0 KBL410 1000 4.0 150 10.0 4.0 1.0
供应6.0AMPERES/ KBJ6X贴片二极管
信息内容：BRIDGE RECTIFIERS dzsc/17/2311/17231111.gif 1603 KBJ6X.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV KBJ6005 50 6.0 175 5.0 3.0 1.1 KBJ601 100 6.0 175 5.0 3.0 1.1 KBJ602 200 6.0 175 5.0 3.0 1.1 KBJ604 400 6.0 175 5.0 3.0 1.1 KBJ606 600 6.0 175 5.0 3.0 1.1 KBJ608 800 6.0 175 5.0 3.0 1.1 KBJ610 1000 6.0 175 5.0 3.0 1.1
