供应小型功率继电器MI-2P糸列
| 价 格： | 面议 | |
| 型号/规格： | MI-SH-205L/MI-SH-209L/MI-SH-212L/MI-SH-224L | |
| 品牌/商标： | GOODSKY |
Application
Cooking Appliances, Air Conditioner, Audio Equipment, Domestic Appliances, Controlling Equivalent, etc.
Performance (at Initial Value)
Contact Resistance.............100mΩMax.@1A,6VDC
Operate Time.......................15 mSec. Max. (D Type)
20 mSec. Max. (L Type)
Release Time......................8 mSec. Max.
Dielectric Strength:
Between Coil & Contact......5,000VAC at 50/60 Hz
for one minute.
Between Contacts...............1,000VAC at 50/60 Hz
for one minute.
Surge Strengt......................10,000V (between Coil
& Contact 1.2x50μSec.)
.....Insulation Resistance..........100 MegaΩ Min. at
500VDC.
Max. On/Off Switching :
Electrical..............................20 Cycles per Minute.
Mechanical..........................300 Cycles per Minute.
Temperature Range.............-30～55°C
Humidity Range...................45～85% RH.
Coil Temperature Rise.........45°C Max. (D Type)
35°C Max. (L Type)
Vibration:
Endurance............................10 to 55 Hz dual
amplitude width 1.5mm.
Error Operation....................10 to 55 Hz dual
amplitude width 1.5mm.
Shock :
Endurance ..........................1,000 m/S2.
Error Operation....................100 m/S2.
Life Expectancy :
Mechanical .........................107 Operations at No
Load condition.
Electrical .............................105 Operations at Rated Resistive Load.
2.5x104 Operations at
TV Rated Load.
Weight..................................About 13.8 g.
Accessories & Sockets
PI-50BE................................See Page 151
PI-50BE/3.............................See Page 151
PI-50-0.................................See Page 152
Safety Standard & Its File Number
UL , CSA , TÜV
FIMKO(L/LM Type)..............FI 11385
SEMKO(L/LM Type).............9834069/01
VDE (MI-D/DM/L/LM Type)..6486ÜG
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 陈树辉
- 电话：0755-82534577/13076512089
- 传真：0755-82534577
- 手机：13686868407
- QQ ：
供应小型功率继电器GJ-SH糸列
信息内容：Main Feature1. Small size (18 x10.3 x15.6 mm) produces a switching capacity up to 10A for high density P.C. Board mounting technique.2. The Contact form construction is 1a (SPST).3. The Surge Strength of GJ Series is 10,000V.4. Sealing Construction (Free from dust and solder flux):GJ-SS: Flow Solder Type.GJ-SH: Plastic sealed type. 5. The selection of plastic insulation material is designed for high temperature and provides better chemical solution performance.
供应小型功率继电器MIH糸列
