供应小型功率继电器GJ-SH糸列
| 价 格： | 面议 | |
| 型号/规格： | GJ-SH-105LM/GJ-SH-112LM/GJ-SH-124LM | |
| 品牌/商标： | GOODSKY |
Main Feature
1. Small size (18 x10.3 x15.6 mm) produces a switching capacity up to 10A for high density P.C. Board mounting technique.
2. The Contact form construction is 1a (SPST).
3. The Surge Strength of GJ Series is 10,000V.
4. Sealing Construction (Free from dust and solder flux):
GJ-SS: Flow Solder Type.GJ-SH: Plastic sealed type.
5. The selection of plastic insulation material is designed for high temperature and provides better chemical solution performance.
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 陈树辉
- 电话：0755-82534577/13076512089
- 传真：0755-82534577
- 手机：13686868407
- QQ ：
供应小型功率继电器MIH糸列
信息内容：Main Feature1.Insulation distance of 8 mm Min. is designed. Theemployment of insulation material is meeting to JIS insulation class E. Dielectric Strength 5,000V Min. and Surge Strength of 10,000V Min. can be reached.2.The employment of suitable plastic materials isapplied under high temperature condition and various chemical solutions.3.Complete protective construction is designed fromdust and soldering flux. If required, plastic sealed type is available for washing procedure. ApplicationCooking Appliances, Air Conditioner, Audio Equipment,Domestic Appliances, Controlling Equivalent, etc.Performance (at Initial Value) Contact Resistance.............100mΩMax.@1A,6VDC Operate Time.......................15 mSec. Max. (D Type)20mSec. Max. (L Type) Release Time......................8 mSec. Max. Dielectric Strength:Between Coil & Contact......5,000VAC at 50/60 Hzfor one minute.Between Contacts...............1,000VAC at 50/60 Hzfor one minute...
供应天豪(SSR)固态继电器SSR48-25A
信息内容：天豪公司为我国较早生产固态继电器的厂家之一。公司引进国外整套先进设备和优质芯片，采用国外先进生产工艺和国际IEC标准，精工制造天豪GTJ型系列固态继电器。企业已通过ISO9001：2000国际质量体系认证。出厂的产品可以替代同类进口产品。产品通过国家一级鉴定单位检测和德国TüV、TüVus认证。 本公司有国外一流技术专家的长期合作和指导，有上千家用户的长期使用和信任，产品被国家许多重点工程采用，部分产品远销东南亚、南非等国家。热诚欢迎新老用户使用本公司产品，我们将为您提供优良的服务。天豪目标：打造世界一流的品牌 天豪精神：诚信 勤奋 和谐 完美 产品通过德国TüV、TüVus认证产品通过CE认证产品通过RoHS测试产品通过国家CCC认证企业通过ISO9001：2000国际质量管理体系认证可替代同类进口产品 dzsc/17/1369/17136908.jpg
