供应2.4GH功率放大器
| 价 格： | 面议 | |
| 型号/规格： | AP08-5000 | |
| 品牌/商标： | 迈信通 |
802.11b/g Signal Amplifier (Indoor use)
|
Model |
AP12-5000 Indoor |
|
Frequency range |
2.4～2.483GHz |
|
Working pattern |
TDD |
|
Launch output |
37dBm (5w) |
|
Launch power input |
Min: 0 dBm Max: 15 dBm |
|
Transmit Gain |
25 dB typical |
|
Receiv Gain |
20 dB typical |
|
Small Signal Gain Flatness |
±1dB |
|
Noise Figure |
＜3.5dB |
|
Switch time delay |
＜1us |
|
protection |
1/4 wavelength short |
|
AGC Control |
No |
|
Coupling |
N-K or SMA Female (50 Ω) |
|
Operating temperature scope |
-25 °C ~55 °C |
|
Indicating lamp |
Transmitter : Green / Receiver : Red |
|
Dimensions |
118*110*30mm |
|
Working voltage |
12VDC |
|
Sample Availability |
|
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 赵崇岭
- 电话：0755-27958183
- 传真：0755-29768625
- 手机：15817464020
- QQ ：
供应WLAN干线放大器
信息内容：Model AP08-0500 Indoor Frequency range 2.4～2.5GHz Working pattern TDD Launch output 27dBm (0.5w) Launch power input Min: 5 dBm Max: 16 dBm Receive power input Max: -5 dBm Receiv Gain 16 dB typical Small Signal Gain Flatness ±1dB Noise Figure ＜3.5dB Switch time delay ＜1us protection 1/4 wavelength short AGC Control Yes Coupling N-K or SMA Female (50 Ω) Operating temperature scope -25 °C ~55 °C Indicating lamp Transmitter : Green / Receiver : Red Dimensions 152*71*25mm Working voltage 12VDC Sample Availability In stock 802.11b/g Signal Amplifier (Indoor use)
供应2.4GH功率放大器
信息内容：802.11b/g Signal Amplifier (Outdoor use) Model AP06-1000 Outdoor Model AP06-2000 Outdoor Frequency range 2.4～2.5GHz Frequency range 2.4～2.5GHz Working pattern TDD Working pattern TDD Launch output 30dBm (1w) Launch output 33dBm (2w) Launch power input Min: 5 dBm Max: 16 dBm Launch power input Min: 5 dBm Max: 16 dBm Receive power input Max: -5 dBm Receive power input Max: -5 dBm Receiv Gain 18 dB typical Receiv Gain 18 dB typical Small Signal Gain Flatness ±1dB Small Signal Gain Flatness ±1dB Noise Figure ＜3.5dB Noise Figure ＜3.5dB Switch time delay ＜1us Switch time delay ＜1us protection 1/4 wavelength short protection 1/4 wavelength short AGC Control Yes AGC Control Yes Coupling N-K or SMA Female (50 Ω) Coupling N-K or ...
