供应信号继电器HJR1-2C/20.3*9.8*11.8
| 价 格： | 5.00 | |
| 型号/规格： | HJR1-2CL-5V/HJR1-2CL-9V/HJR1-2CL-12V/HJR1-2CL-24V | |
| 品牌/商标： | TECO天波 |
| dzsc/16/2397/16239746.jpg | ||||||||||||||||||||||||||||||||||||||||||||||
| dzsc/16/2397/16239746.gifHideTechnical Data
|
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 陈树辉
- 电话：0755-82534577/13076512089
- 传真：0755-82534577
- 手机：13686868407
- QQ ：
供应通用继电器HJQ-15F/32.2*27.3*20.2
信息内容：通用继电器 本页:1 产品数: 9 1/1 型号 外型 触点负载 外型尺寸(mm) 安规认证 Order HJQ-13F-1C 16A 250VAC16A 30VDC 35.0×21.5×28.0 UL,CUL：E173485CQC：03001006459TUV：R50031316. HJQ-13F-2C 10A 250VAC10A 30VDC15A 125VAC 35.0×21.5×28.0 UL,CUL：E173485CQC：03001006458TUV：R50031316. HJQ-15F NC：15A 240VAC 15A 28VDCNO：25A 240VAC 25A 28VDC 32.2×27.2×20.4 UL,CUL：E173485CQC：03001003709TUV：R50031316. HJQ-15F-1 NC：15A 240VAC 15A 28VDCNO：25A 240VAC 25A 28VDC 32.4×24.5×27.8 UL,CUL：E173485CQC：03001003709TUV：R50031316. HJQ-15F-2 NC：15A 240VAC 15A 28VDCNO：25A 240VAC 25A 28VDC 32.4×27.8×20.0 UL,CUL：E173485CQC：03001003709TUV：R50031316. ...
供应TR-7FF-S-Z电磁继电器
信息内容：TR-7FF-S-Z PC Board Relay dzsc/16/2397/16239748.jpg dzsc/16/2397/16239748.gifHideTechnical Data CONTACT DATA Contact Form 1A/1C Contact Material Silver Alloy Contact Ratings 1A:10A 240VAC 1C:10A 120VAC 12A 120VAC/24VDC 7A 240VAC/24VDC Max Switching Voltage 250VAC/30VDC Max Switching Current 12A Max Switching Power 2770VA/240W Contact Resistance 100mΩMax at 6VDC 1A Life Expectancy Electrical 100,000 Operations(at30Operations/minute) Life Expectancy Machanical 10,000,000 Operations GENERAL DATA Insulation Resistance 100MΩMin at 500VDC Dielectric Strength Between Open Contacts 750VAC(for one minute) Between Contacts and coil 1500VAC(for one minute) Operate Time 10ms Release Time 5ms Temperature Range -40℃to+70℃ Shock Resistance Operating Extremes 10G Shock Resistance Damage Limits 100G Vibration Resistance 10-55Hz,1.5mm Humidity 40-85% Weight Approx 10g
