供应TR-7FF-S-Z电磁继电器
| 价 格： | 5.00 | |
| 型号/规格： | TR-7FF-S-Z | |
| 品牌/商标： | TECO天波 |
TR-7FF-S-ZPC Board Relay |
dzsc/16/2397/16239748.jpg | |||||||||||||||||||||||||||||||||||||||||||||
| dzsc/16/2397/16239748.gifHideTechnical Data
|
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 陈树辉
- 电话：0755-82534577/13076512089
- 传真：0755-82534577
- 手机：13686868407
- QQ ：
供应TR-21FF-S-Z电磁继电器
信息内容：TR-21FF-S-Z PC Board Relay dzsc/16/2397/16239749.jpg dzsc/16/2397/16239749.gifHideTechnical Data CONTACT DATA Contact Form 1A/1C Contact Material Silver Alloy Max Switching Voltage 250VAC/30VDC Max Switching Current 15A Max Switching Power 2770VA/240W Contact Resistance 100mΩMax at 6VDC 1A Life Expectancy Electrical 100,000 Operations(at30Operations/minute) Life Expectancy Mechanical 10,000,000 Operations GENERAL DATA Insulation Resistance 100MΩMin at 500VDC Dielectric Strength Between Open Contacts 750VAC(for one minute) Between Contacts and coil 1500VAC(for one minute) Operate Time 10ms Release Time 5ms Temperature Range -40℃to+85℃（105℃） Shock Resistance Operating Extremes 10G Shock Resistance Damage Limits 100G Vibration Resistance 10-55Hz,1.5mm Humidity 40-85% Weight Approx 13g
供应TR-3FF-S-Z电磁继电器
信息内容：TR-3FF-S-Z PC Board Relay dzsc/16/2397/16239750.jpg dzsc/16/2397/16239750.gifHideTechnical Data CONTACT DATA Contact Form 1A/1C Contact Material Silver Alloy Max Switching Voltage 250VAC/30VDC Max Switching Current 15A Max Switching Power 2770VA/240W Contact Resistance 100mΩMax at 6VDC 1A Life Expectancy Electrical 100,000 Operations(at30Operations/minute) Life Expectancy Machanical 10,000,000 Operations GENERAL DATA Insulation Resistance 100MΩMin at 500VDC Dielectric Strength Between Open Contacts 750VAC(for one minute) Between Contacts and coil 1500VAC(for one minute) Operate Time 10ms Release Time 5ms Temperature Range -40℃to+85℃（105℃） Shock Resistance Operating Extremes 10G Shock Resistance Damage Limits 100G Vibration Resistance 10-50Hz 1.5mm Humidity 40—85% Weight Approx 10g
