interface高转速超小量程动态扭矩传感器

Model T11 Bearingless
Rotary Torque Transducer
Why the Interface model T11 Bearingless
Rotary Torque Transducer is the best in class:
 Capacities from 0.005 to 150 Nm
 (0.04 to 1,327 lb-in)
 Bearingless
 High speed - to 30K RPM
 +5 VDC output
 Very low range
 Eliminates bearing friction effects
 10 kHz sample rate
 12-28 VDC supply
 16-bit resolution

               SPECIFICATIONS
ACCURACY – (MAX ERROR)
Combined Error–% FS ........................±0.1
Nonrepeatability–% ............................±0.02
TEMPERATURE
Effect on Zero–% RO/C ......................±0.02
Effect on Output–%/C ........................±0.01
Rated Range–C ..................................+5 to +45
Operating Range–C ............................+0 to +60
ELECTRICAL
Output–VDC ........................................±5
Bandwidth, Hz ....................................3 kHz-3dB
Calibration Signal–% RO ....................100
Supply Voltage–VDC............................12 to 28
Supply Current–mA ............................60
Electrical Connection ..........................8-pin
MECHANICAL
Safe Overload–% RO ..........................200
Cyclic Load Rating–% RO....................±70 peak
Max Speed - rpm ................................30K - see table
Shaft....................................................Stainless steel
Housing ..............................................Aluminum
