美国雷博非接触式扭矩传感器

F E A T U R E S :
- Built-in instrumentation amplifier
(±10 V output)
- Contactless
- Single supply voltage
- Compact size
- Wide application range
O P T I O N S :
- Speed sensing (S) option
- Angle encoder (E) option
These transducers are suitable for laboratory applications as
well as industrial evironments because of their compact size
and multiple mounting options. The contactless transmission
of supply voltage and measuring signal enables continuous
operation with low maintenance.
Torque transducers

P E R F O R M A N C E S P E C S :
1700 SERIES
SPECIFICATIONS  1700 /1701/ 1702 /1703/ 1706
Capacity range: 0.02; 0.05 Nm /0.1; 0.2; 0.5; 1; 2 Nm /5; 10; 20 Nm /50; 100; 200; 300 Nm /500; 1,000, 1,500 Nm
Supply voltage: 12 VDC ±10%
Current consumption: less than 200 mA
Rise time: 2 ms  1 ms (1 Hz)
Limit frequency—3dB: 200 Hz
Voltage output: 0 to ±10 V
Internal resistance: 100 ?
Ripple: <100mVpp
Overall accuracy: <0.25%
Operating temperature: 0-60ºC
Compensated temperature range: 5-45ºC
Temperature error:
Zero point: 0.02%/K
Sensitivity: 0.01%/K
Mechanical overload: 200%
of rated output
Weight: approx. 200g    approx. 200g approx. 600g approx. 1300g approx. 4500g
Max. sensor speed (RPM): 15,000/ 37,000/ 19,000 /13,500 /7,900
