ABB分析仪表溶解氧分析仪AX480/468型

品牌	ABB	型号	AX480,AX488,AX468
类型	便携式溶氧仪	测量范围	见参数表
精确度	见参数表	分辨率	见参数表
尺寸	见参数表（mm）

Dissolved Oxygen Analyzer AX480

The Dissolved Oxygen Analyzer AX480 is used with 9408 sensing systems to provide accurate measurement of the dissolved oxygen value in a range of water monitoring applications. The measured value can be transmitted via fully isolated current outputs. The analyzer incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications. It is rugged and reliable for safe operation in harsh environments, simple to install and use, and requires minimum maintenance. Applications include Municipal waste-water treatment, aerobic effluent treatment in Pulp & Paper and Food & Beverage, and Fish Farming.

• Range 0 ... 20 ppm and 0 ... 200 % saturation
• Sensor life indicator
• Salinity and atmospheric pressure correction capability as standard
• Wall-, pipe- and panel-mount versions with IP 66 / NEMA 4X ingress protection
• Continuous in-line diagnostics providing reduction in operating costs
• Auto-Jet wash / Air clean - significantly reduces maintenance
• Integral P, PI, PID Control: pulse frequency, pulse-length and analog
• Real-time clock and log book records alarm events
• 2 to 4 current outputs and 3 to 5 relay contacts
• Versatile power supply options: 85 ... 265 V AC or 12 ... 30 V DC
• High visibility, multi-language display

Dissolved Oxygen Analyzer AX488

The Dissolved Oxygen Analyzer AX488 enables two continuous measurements of dissolved oxygen with simultaneous local display and transmission via analog outputs. The analyzer is used with 9408 sensing systems to provide accurate measurement of the dissolved oxygen value in a range of water monitoring applications. The analyzer incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications. It is rugged and reliable for safe operation in harsh environments, simple to install and use, and requires minimum maintenance. Applications include Municipal waste-water treatment, aerobic effluent treatment in Pulp & Paper and Food & Beverage, and Fish Farming.

• Cost-effective, lower investment compared to separate instruments
• Range 0 ... 20 ppm and 0 ... 200 % saturation
• Sensor life indicator
• Salinity and atmospheric pressure correction capability as standard
• Wall-, pipe- and panel-mount versions with IP 66 / NEMA 4X ingress protection
• Continuous in-line diagnostics providing reduction in operating costs
• Auto-Jet wash / Air clean - significantly reduces maintenance
• Real-time clock and log book records alarm events
• 2 to 4 current outputs and 3 to 5 relay contacts
• Versatile power supply options: 85 ... 265 V AC or 12 ... 30 V DC
• High visibility, multi-language display

pH / Redox (ORP) & Dissolved Oxygen Analyzer AX468

The pH / Redox (ORP) & Dissolved Oxygen Analyzer AX468 is designed for use with ABB’s pH systems and 9408 dissolved oxygen sensors. The cost-saving analyzer measures pH and dissolved oxygen simultaneously, with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications. The AX468 is rugged and reliable for safe operation in harsh environments, simple to install and use, and requires minimum maintenance. Applications include Municipal waste-water treatment, aerobic effluent treatment in Pulp & Paper and Food & Beverage, and Fish Farming.

• Two sensors, one instrument - reduces cost of investment
• Accurate measurements up to 14 pH, 0 ... 20 ppm and 0 ... 200 % saturation
• Sensor life indicator
• Salinity and atmospheric pressure correction capability as standard
• Wall-, pipe- and panel-mount versions with IP 66 / NEMA 4X ingress protection
• Continuous in-line diagnostics providing reduction in operating costs
• Auto-Jet wash - significantly reduces maintenance
• Real-time clock and log book records alarm events
• 2 to 4 current outputs and 3 to 5 relay contacts
• Versatile power supply options: 85 ... 265 V AC or 12 ... 30 V DC
• High visibility, multi-language display
