德国PTL试验指
- 价 格：
- 12000
- 型 号：
- P10.48 P10.49
- 品牌/商标：
- PTL
- 企业类型：
- 贸易商
- 新旧程度：
- 全新
- 原产地：
- 德国
德国PTL试验指
德国PTL 试验指 IEC60335/EN950试验指 PTL优质供应商
PTL 测试指,探针，探棒用于测试避免接触危险部位和进入固体异物.
PTL Access And Object Probes
for testing the protection against access to hazardous parts and against ingress of solid foreign objects
Rigid Test Finger
With insulated Part 20mm x Φ50mm,
1000 long,according to
IEC 60335-1/4.91&22.11 Fig 10.
EN 60950/1992&4.2.2.
VDE0631 Part 1/ 3.93&8.1.5.1
With dynamometer 0......50N c),d) Article No: P10.48
With dynamometer 0......100N c),d) Article No: P10.49
Without dynamometer a).b),c) Article No: P10.15
Workmanship: The active parts of the test fingers and-pins consist of hardened stainless stell. The isolating parts are made of POM (Polyoxymethylene)
a) with longitudinal bore Φ 12mm at the end of the handle to pin up at the rod Φ 12mm of a Push and Pull Dynamometer
b) with longitudinal bore Φ 4mm in the handle to connect a test lead with banana plug
c) with radial bore Φ 4mm in the handle to connect a test lead with banana plug necessary if a Push and Pull Dynamometer is mounted
d) with eyelet and key ring at the rod protruding from the handle, to measure pull forces. E.g.with the test Hook P10.40
e) to pin up at a Push and Pull Dynamometer by means of Adapter Φ 12mm/Φ 10mm Article No. P10.61
f) with rod Φ 12mm at one end to apply push forces, e.g. to the probes marked with a)
