横河WT5000高功率分析仪 *新品上市
深圳市科瑞杰科技有限公司-日本横河YOKOGAWA WT5000具有的精--确度和模块化的构架，让工程师们能够兼顾与灵进行，并充满自信地将概念快速转化为产品，走向市场。
主要特性与技术指标
性 – WT5000能够&plun;0.03%以内的精--确度、500次的谐波比较、用户自定义运 算、可信赖的多通道测量。
通用性 – WT5000有7个插槽，用户可更换功 率单元，还提供多样化选择，便于用户根据应用和需求变化扩展和更改配置。此外，还可同时测量4台电机的速度和扭矩。
简易性 – 全触屏体验，辅以硬件按键及 大的远程测量软件，连接、配置和测量功率变得简单。
Reliable Today, Ready for Tomorrow
Make measurements you can trust with a guaranteed accuracy of *0.03%
10MS/s, 1MHz power bandwidth, 18 bit resolution enabled by Yokogawa isoPRO™ fiber optic isolation technology
Simultaneously yze 7 phases with one chis, producing over 1000 power parameters real-time
Precision current measurement guaranteed by innovative symmetric coaxial shunt design
*basic power accuracy
Innovate with Precision, Flexibility and Confidence
Modular architecture with 7 user swappable and reconfigurable input elements
Synchronize multiple chis for large multi-phase systems
For motors and generators up to 4 speed and torque inputs** can be used measuring total system efficiency
Isolate and measure harmonic losses with configurable advanced filtering for simultaneous wideband and harmonic power ysis
**can be configured as auxiliary inputs
Precision Made Easy
Highly responsive 10.1 inch electrostatic capacitive touch screen
Intuitive and easy menus to connect, configure, measure and record
Modular interconnect design putting safety first
Unmatched Accuracy
The WT5000 is the world’s most accurate precision power yzer with a basic power accuracy of &plun;0.03%. Its accuracy specifications are guaranteed from 1% to 130% of the selected voltage and current ranges. With minimum influence of low power factor (0.02% of apparent power) the unit is also accurate at large phase shifts and frequencies.
AC power accuracy: 0.01% of reading + 0.02% of range
DC power accuracy: 0.02% of reading + 0.05% of range
10 MS/s 18 bit ADC
Multi-channel Measurements
Measure from up to 7 different power phases at 10 MS/s (18 bits). The high resolution, 10.1 inch WXGA display allows split screen viewing of up to 7 waveforms and can display up to 12 pages of diverse measurement parameters, making it ideal for efficiency tests of inverter driven motors, renewable energy technologies and traction applications like pumps, fans and electric vehicles. Measurements are also displayed in vector format or trending in time.
Intuitive Operation
Operable by touch and/or hardware hot-keys independently, the WT5000 offers a seamless and intuitive experience that makes connecting, configuring and measuring easier than ever before. The 10.1 inch WXGA touchscreen delivers excellent noise immunity even in high noise environments such as motors and inverters.
Advanced Filtering
In addition to low p frequency filters and line filters, the WT5000 features advanced filtering capabilities that provide unprecedented control to yze even the toughest of waveforms with precision.
Synchronization source filter: Instead of synchronizing to zero crossings, users can select any specific point of the synchronization source signal.
Enhanced frequency filter: Allows users to simultaneously measure fundamental and switching frequencies without influencing any other parameter.
Dial Parallel Path filters: Supported by a high frequency anti-aliasing filter, two separate line filters for normal and harmonic measurements ensures accuracy without aliasing in wide band and harmonic measurements. Users can limit the number of harmonic orders to eliminate attenuation in low bandwidth measurements.
Advanced Harmonic ysis
Evaluate and compare input and output harmonics of inverters, motors or power conditioners up to the 500th order. The WT5000 allows users to not only measure harmonics and power simultaneously but also offers side by side comparison of harmonics from two different input sources.
The effects of noise and aliasing are minimized by antialiasing and line filters with Dial Parallel Path technology allowing simultaneous power ysis of wide band and narrow band components.
Custom Triggers and Computations
Define and use event triggers and custom computations as per application needs. The event trigger function allows users to set limits to capture readings that fall within or outside a specific range of power, current or other parameters. Users can also define and use up to 20 different expressions for custom calculations. Data that meets the trigger conditions can be stored, printed, or saved to a U memory device.
