连云港开发区思创电子有限公司为的的整流二管生产厂家，为国内各大汽车整流器厂商提供整流粒子，整流桥，质量稳定，。
产品远销国内外，欢迎新老客户来电咨询。
联系人：许素珍 销售主管
联系电话：
|
SYOL |
| AR354 / ARS354 |
|
UNITS | ||||
峰值反向電壓 Maximum recurrent reverse voltage |
VRRM |
|
|
400 |
|
|
Volts | ||
RMS輸入電壓 Maximum RMS voltage |
VRMS |
|
|
280 |
|
|
Volts | ||
直流阻斷電壓 Maximum DC blocking voltage |
VDC |
|
|
400 |
|
|
Volts | ||
平均正向整流電流 Maximum erage forward rectified current at Tc=60℃ |
I(AV) |
35 |
Amps | ||||||
正向峰值浪涌電流 Peak forward surge current single sine-we on rated load (JEDEC Method) |
IFSM |
300 |
Amps | ||||||
35A時正向瞬間電壓降 Maximum instantaneous forward voltage drop at6A,Tj=25℃ |
VF |
1.0 |
Volts | ||||||
反向漏電流 Maximum DC reverse current TA=25℃ at rated DC blocking voltage TA=100℃ |
IR |
5.0 100.0 |
μA | ||||||
工作溫度和存儲溫度 Operating and Storage Temperature Range | TJ TSTG |
-55 TO +150 | ℃ | ||||||
