尺寸规格图:
| Wire Range mm2/Awg 适用电线 | Item No.料号 | NEMA TAB | Dimension(mm/inch)主要尺寸 | Insulation Color 护套颜色 | Q'TY BOX包装量 | ||||
| W | F | L | d1 | T | |||||
| 0.5-1.5mm222-16AWG | CP1.25-187(5)FNM | .020*.187 (0.5*4.75) | 5.0(.197) | 7.0(.276) | 15.2(.598) | 1.7(.067) | 0.4(.016) | Red | 1000 |
| CP1.25-187(8)FNM | .032*.187 (0.8*4.75) | 1000 | |||||||
| CP1.25-250(8)FNM | .032*.250 (0.8*6.35) | 6.6(.260) | 7.6(.299) | 16.0(.630) | 1000 | ||||
| 1.5-2.5mm216-14AWG | CP2-187(5)FNM | .020*.187 (0.5*4.75) | 5.0(.197) | 7.0(.276) | 15.2(.598) | 2.3(.091) | 0.4(.016) | Blue | 1000 |
| CP2-187(8)FNM | .032*.187 (0.8*4.75) | 1000 | |||||||
| CP2-250(8)FNM | .032*.250 (0.8*6.35) | 6.6(.260) | 7.6(.299) | 16.0(.630) | 1000 | ||||
| 4-6mm2 12-10AWG | CP3.5-250FNM | .032*.250 (0.8*6.35) | 6.6(.260) | 7.6(.299) | 16.5(.650) | 3.4(.134) | 0.4(.016) | Yellow | 1000 |
