CBB13型 箔式聚丙烯膜电容器（高压，高频）
Polropylene Film Dielectric Metal Foil Capacitors Te CBB13
外型图Outline drawing
产品介绍Introduction
采用聚丙烯膜作介质，铝箔作电卷绕而成，无感结构，环氧树脂包封，单向引出。
The polropylene film as the dielectric and aluminum foil as the electrode , non-inductive construction, epoxy rin coated and radial CP wire.
特点Characteristic
●优异的频率、温度特性 Excellent frequency and temperature characteristics
●能承受大电流的冲击 Can operating in over rate current strike.
用途Usage
广泛用于灯、电子整流器以及其它高频、高压电路。
Widely used in electronic ballast and other high voltage, high frequency circuit.
引用标准Reference Standard
GB10188-88
性能指标Specifications
使用温度范围 Operating temp range | -45℃～+85℃ | |
容量范围 Capacitance range | 0.001～0.1μF | |
额定电压 Rated voltage | 400V、630V、1000V | |
电容量偏差 Capacitance tolerance | &plun;5%(J)、&plun;10%(K) | |
损耗角正切 Dissipation factor | ≤10X10-4 (23℃ f= 10KHz) | |
耐电压 Withstand voltage | 2.0UN(10S) | |
缘电阻 Insulation ristance | Rs≥30000MΩ | (23℃ 1min) |
