1.导线截面：有0.5-1.5平方毫米,1.5-2.5平方毫米,2.5-4平方毫米,4-6平方毫米.
2.端头材料:紫铜;缘材料:PVC;
| Cable size:0.5~1.5mm2(A.W.G22-16) Max current:lmax=19A Material:purple copper | ||||||||
| ITEM.. | USA screw | screw dia. d2(mm) | DIMENSION(mm) | COLOR | ||||
| B (mm) | L (mm) | F (mm) | H (mm) | Dφ (mm) | ||||
| RV1.25-3 | #4 | 3.2mm | 5.7 | 17.8 | 5.0 | 10.0 | 4.3 | Red |
| RVS1.25-3.5 | #6 | 3.7mm | 5.7 | 17.8 | 5.0 | |||
| RVM1.25-3.5 | #6 | 3.7mm | 6.6 | 20.1 | 6.3 | |||
| RVL1.25-3.5 | #6 | 3.7mm | 8.0 | 21.5 | 7.0 | |||
| RVS1.25-4 | #8 | 4.3mm | 6.6 | 20.1 | 6.3 | |||
| RVL1.25-5 | #8 | 4.3mm | 8.0 | 21.5 | 7.0 | |||
| RV1.25-5 | #10 | 5.3mm | 8.0 | 21.5 | 7.0 | |||
| RV1.25-6 | 1/4 | 6.5mm | 11.6 | 27.5 | 11.1 | |||
| RV1.25-8 | 5/16 | 8.4mm | 11.6 | 27.5 | 11.1 | |||
| RV1.25-10 | 3/8 | 10.5mm | 13.6 | 31.6 | 13.9 | |||
| Cable size:1.5~2.5mm2(A.W.G16-14) Max current:lmax=27A Material:purple copper | ||||||||
ITEM.. | USA screw | screw dia. d2(mm) | DIMENSION(mm) | COLOR | ||||
| B (mm) | L (mm) | F (mm) | H (mm) | Dφ (mm) | ||||
| RV2-3 | #4 | 3.2mm | 6.6 | 17.8 | 4.3 | 10.0 | 4.9 | Blue |
| RVS2-3.5 | #6 | 3.7mm | 6.6 | 17.8 | 4.3 | |||
| RVM2-3.5 | #6 | 3.7mm | 6.6 | 21.0 | 7.0 | |||
| RVL2-3.5 | #6 | 3.7mm | 8.5 | 22.5 | 7.8 | |||
| RVS2-4 | #8 | 4.3mm | 6.6 | 21.0 | 7.0 | |||
| RVL2-4 | #8 | 4.3mm | 8.5 | 22.5 | 7.8 | |||
| RVS2-5 | #10 | 5.3mm | 8.5 | 22.5 | 7.8 | |||
| RVL2-5 | #10 | 5.3mm | 9.53 | 22.5 | 7.25 | |||
| RV2-6 | 1/4 | 6.4mm | 12 | 27.6 | 11 | |||
| RV2-8 | 5/16 | 8.4mm | 12 | 27.6 | 11 | |||
| RV2-10 | 3/8 | 10.5mm | 13.6 | 30.2 | 13.9 | |||
| Cable size:2.5~4mm2(A.W.G14-12) Max current:lmax=37A Material:purple copper | ||||||||
| ITEM.. | USA screw | screw dia. d2(mm) | DIMENSION(mm) | COLOR | ||||
| B (mm) | L (mm) | F (mm) | H (mm) | Dφ (mm) | ||||
| RV3.5-4 | #8 | 4.3mm | 8.0 | 24.5 | 7.7 | 13.0 | 6.2 | Black |
| RVS3.5-5 | #10 | 5.3mm | 8.0 | 24.5 | 7.7 | |||
| RVL3.5-5 | #10 | 5.3mm | 12.0 | 27.9 | 7.7 | |||
| RV3.5-6 | 1/4 | 6.5mm | 12.0 | 27.9 | 7.7 | |||
| Cable size:4~6mm2(A.W.G12-10) Max current:lmax=48A Material:purple copper | ||||||||
| ITEM.. | USA screw | screw dia. d2(mm) | DIMENSION(mm) | COLOR | ||||
| B (mm) | L (mm) | F (mm) | H (mm) | Dφ (mm) | ||||
| RV5.5-3.5 | #6 | 3.7mm | 7.2 | 21.4 | 5.9 | 13.0 | 6.7 | Yellow |
| RVS5.5-4 | #8 | 4.3mm | 7.2 | 21.5 | 5.9 | |||
| RVL5.5-4 | #8 | 4.3mm | 9.5 | 25.5 | 8.3 | |||
| RV5.5-5 | #10 | 5.3mm | 9.5 | 25.5 | 8.3 | |||
| RV5.5-6 | 1/4 | 6.5mm | 12 | 31.5 | 13 | |||
| RV5.5-8 | 5/16 | 8.4mm | 15 | 33.7 | 13.7 | |||
| RV5.5-10 | 3/8 | 10.5mm | 15 | 33.7 | 13.7 | |||
| RV5.5-12 | 1/2 | 13.0mm | 19.2 | 38.1 | 16 | |||
