| downlight | 7W | 15W | 24W | 15W with gl | False False Bitmap | 60W with gl |
| ceiling light | False False Bitmap | False False Bitmap | False False Bitmap | False False Bitmap | | False False Bitmap |
| |
| 产品名称Name | LED 筒灯House Ceiling Lights | LED 筒灯House Ceiling Lights | LED 筒灯House Ceiling Lights | LED 筒灯House Ceiling Lights | LED 筒灯House Ceiling Lights | LED 筒灯House Ceiling Lights |
| 产品型号Part Number | NKX-24/4-007/1-CA | NKX-24/4-015/1-CB | NKX-24/4-024/1-CC | NKX-24/4-015/1-CD | NKX-24/4-024/1-CE | |
| 输入功率Input Power | 7W | 15W | 24W | 15W | 24W | 60W |
| 光源光通量Luminous Flux | 560 lm | 1200 lm | 1920 lm | 1200 lm | 1920 lm | 4800lm |
| 灯具光效Luminous Efficiency | 55 lm/w | 55 lm/w | 55 lm/w | 50 lm/w | 50 lm/w | 55lm/w |
| 输入电压Voltage | 100/110/120 220/230/240VAC(交流) | 100/110/120 220/230/240VAC(交流) | 100/110/120 220/230/240VAC(交流) | 100/110/120 220/230/240VAC(交流) | 100/110/120 220/230/240VAC(交流) | 90-277 |
| 工作电流Current | 50mA 25mA | 100mA 50mA | 160mA 80mA | 100mA 50mA | 160mA 80mA | |
| 工作频率Frequency | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz |
| 功率因数AC Power Factor | 45.00% | 45.00% | 45.00% | 45.00% | 45.00% | 45.00% |
| 功率DC Power Efficiency | 94% | 94% | 94% | 94% | 94% | 94% |
| 发光角度Beam Angle | 107°(50%) | 107°(50%) | 93°(50%) | 107°(50%) | 93°(50%) | 107°(50%) |
| 色温Color Temperature | 3500K/6500K | 3500K/6500K | 3500K/6500K | 3500K/6500K | 3500K/6500K | 3500K/6500K |
| 显色指数Color Rendering Index | Ra＞80 | Ra＞80 | Ra＞80 | Ra＞80 | Ra＞80 | Ra＞80 |
| 光源寿命Light Source Life | 50000h | 50000h | 50000h | 50000h | 50000h | 50000h |
| 环境温度Working Temperature | - 40℃～+ 50℃ | - 40℃～+ 50℃ | - 40℃～+ 50℃ | - 40℃～+ 50℃ | - 40℃～+ 50℃ | - 40℃～+ 50℃ |
| 相对湿度Working Humidity | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% |
| 材料Housing ＆Lampshade | 铝合金aluminium alloy | 铝合金aluminium alloy | 铝合金aluminium alloy | 铝合金aluminium alloy | 铝合金aluminium alloy | 铝合金aluminium alloy |
| 护等级IP Rating | IP20 | IP20 | IP20 | IP20 | IP20 | IP20 |
| 灯具颜色Color | 银灰silver gray | 银灰silver gray | 银灰silver gray | 银灰silver gray | 银灰silver gray | 银灰silver gray |
| 外形尺寸Size | Φ101X74(mm) | Ф140X92(mm) | Ф191X125(mm) | Ф147X93(mm) | Ф193X142(mm) | Ф193X142(mm) |
| 包装尺寸Package Dimension | 80<Φ <95(mm) | 170< Ф<180(mm) | 170<Ф<180(mm) | 124<Ф<137(mm) | 167<Ф<186(mm) | 167<Ф<186(mm) |
| 安装方式Installation | 640X390X265(mm) | 575X390X285(mm)(12pcs) | 720X485X375(mm)(12pcs) | | | |
| 毛重G.W/净重N.W | 嵌入式recessed | 嵌入式recessed | 嵌入式recessed | 嵌入式recessed | 嵌入式recessed | 嵌入式recessed |
| | 11.5kg(30pcs)/0.3kg | 6.1kg(12pcs)/0.3kg | 9.2kg(12pcs)/0.4kg | 6.1kg(12pcs)/0.3kg | 9.2kg(12pcs)/0.4kg | 3kg/1.1kg |
