| Model | FAS-3 / FAS024P series | ||||||
| DC Output (O/P) | DC voltage | 12V | |||||
| Rated current | 2.0A | ||||||
| Current range | 0~2.0A | ||||||
| Ripple & Noise (max) | 120mVp-p | ||||||
| Rated power | 24W | ||||||
| Voltage tolerance | &plun;5.0% | ||||||
| Setup, rising time | 500ms, 50ms at full load | ||||||
| Hold up time | >5ms at full load | ||||||
| Input (I/P) | Rated Voltage range | 100~240VAC | |||||
| Frequency range | 47~63Hz | ||||||
| Efficiency (average) | >82.1% (min) | ||||||
| AC current | 0.5A(max) | ||||||
| Leakage current | < 0,25 mA at 250 V | ||||||
| Inrush current | < 60 A at 230 V | ||||||
| Protection | Short circuit te | Hiccup mode , but can't damage for permanent short circiut. | |||||
| Over voltage te | 115~150% rated voltage and Shut off O/P voltage, re-power on to recover | ||||||
| Over load te | 115~200% rated output power and Hiccup model, no damage, automatic recover after removing over load condition | ||||||
| Environment | Working temp | 0 ~+40℃ | |||||
| Working humidity | 20 ~90% RH non-condensing | ||||||
| Storage temp & humidity | -20~+85℃, 10~95% RH | ||||||
| Vibration | EN 61131-2 | ||||||
| Safty & EMC | Standards | design refer to EN60950 | |||||
| Withstand voltage | I/P-O/P: 3KVAC, 5mA, 60S | ||||||
| Isolation resistance | I/P-O/P: 100M ohms/500VDC | ||||||
| EMC | EN55022 Cl B | ||||||
| Others | Certification | CE | |||||
| MTBF | 300 Khrs, Mil-HDBK-217F(25℃) | ||||||
| Connection | IEC 320-C8 plug; 2468/2464/1185 18-22AWG wire, DC jack size and is customized, such as 5.5x2.1x10mm, 3.5x1.35x10m etc. | ||||||
| Dimension | 96*43.5*32mm (L*W*H) | ||||||
| Weight | 133g (Net weight without AC cable) | ||||||
| Mounting | desk te | ||||||
| RoHS compliance | Yes | ||||||
| Warranty Period | 2 year | ||||||
