AC.CAPACITORS(Y1:250VAC AND 400VAC)■Applications●For use in ciruit where alternating,pulsating,intermittent and steady high voltager exist.■Specifications
| Operating Temp.Rang | -25℃ to +85℃ | |||||||
| Rated Voltage | Applicable Standards | X1 | Y1 | |||||
| CSA,UL | 250VAC | |||||||
| SEMKO,SEV,FIMKO,CHINA,KOREA NEMKO,DEMKO,VDE(0565 Teil 1-1) | 400VAC | 400VAC | ||||||
| Dieleric Withstanding Voltage | Rated Voltage | Tt Voltage | ||||||
| 400VAC | 4000VAC for 1 min | |||||||
| Capacitance | Range | 10pf to 4700pf、measured at 1KHz &plun;10%、1.0-5.0Vrms、25℃ | ||||||
| Dissipation Faor (D.F) | Y5P | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | ||||||
| Y5U | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | |||||||
| Y5V | TANδ≤5.0%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | |||||||
| Insulation Ristance | 10000MΩ at 500VDC for 1 minute. | |||||||
| Temperature Charaeristics | Te Code | Tolerance | Cap.Change | Temp.Range | ||||
| Y5P | &plun;10% | +10%、-10% max. | -25℃ to +85℃ | |||||
| Y5U | &plun;10%、&plun;20% | +22%、-56% max. | -25℃ to +85℃ | |||||
| Y5V | &plun;20% | +30%、-80% max. | -25℃ to +85℃ | |||||
| The reference temperature: 25℃ | ||||||||
Y1 SERI■INTRODUIONThe Ceramic Disc Capacitors are specifically digned for AC applications and meet the safety requirements of various safety standards agenci.The capacitors are ideal for across the line and line by-p applications■FEATUR●Ideal for across the line applications ●Compa size ●Cost effeive produ ●Safety standards recognized for AC applications■Part Nuer Configuration JD 102 K Y5P Y1 ①AC capacitors,safety ④Te code:Y5P,Y5U,Y5V ① ② ③ ④ ⑤ ②Rated capacitance ⑤Cl Y1 ③Tolerance on rated capacitance■CAPACITANCE AND DIMENSIONSWhere ordering safety standard recognized ceramic capacitors please use the part nuers as ted above Rated Y1,X1：AC250V AND A00V Dieleric strength：4000VAC
| PART NUER | T.C. | CAP. | TOL. | DIMENSION(mm) | ||
| D(max) | F | T(max) | ||||
| JD10KY5P Y1 To JD82KY5P Y1 | &plun;10% (Y5P) | 10PF to 82PF | K &plun;10% | 7.0 | 9.5&plun;0.8 | 7.0 |
| JD101KY5P Y1 | 100PF | 7.0 | 9.5&plun;0.8 | 7.0 | ||
| JD151KY5P Y1 | 150PF | 7.0 | 9.5&plun;0.8 | 7.0 | ||
| JD221KY5P Y1 | 220PF | 8.0 | 9.5&plun;0.8 | 7.0 | ||
| JD331KY5P Y1 | 330PF | 8.0 | 9.5&plun;0.8 | 7.0 | ||
| JD471KY5P Y1 | 470PF | 7.0 | 9.5&plun;0.8 | 7.0 | ||
| JD561KY5P Y1 | 560PF | 8.5 | 9.5&plun;0.8 | 7.0 | ||
| JD681KY5P Y1 | 680PF | 9.5 | 9.5&plun;0.8 | 7.0 | ||
| JD102KY5P Y1 | 1000PF | 12.0 | 9.5&plun;0.8 | 7.0 | ||
| JD102KY5U Y1 | +22～-56% (Y5U) | 1000PF | K&plun;10% | 9.0 | 9.5&plun;0.8 | 7.0 |
| JD471MY5U Y1 | 470PF | M &plun;20% | 7.0 | 9.5&plun;0.8 | 7.0 | |
| JD561MY5U Y1 | 560PF | 8.0 | 9.5&plun;0.8 | 7.0 | ||
| JD681MY5U Y1 | 680PF | 8.0 | 9.5&plun;0.8 | 7.0 | ||
| JD102MY5U Y1 | 1000PF | 8.0 | 9.5&plun;0.8 | 7.0 | ||
| JD152MY5U Y1 | 1500PF | 9.0 | 9.5&plun;0.8 | 7.0 | ||
| JD222MY5U Y1 | 2200PF | 11.0 | 9.5&plun;0.8 | 7.0 | ||
| JD332MY5U Y1 | 3300PF | 13.0 | 9.5&plun;0.8 | 7.0 | ||
| JD472MY5U Y1 | 4700PF | 15.0 | 9.5&plun;0.8 | 7.0 | ||
| JD102MY5V Y1 | +30～-80% (Y5V) | 1000PF | M &plun;20% | 7.0 | 9.5&plun;0.8 | 7.0 |
| JD152MY5V Y1 | 1500PF | 8.5 | 9.5&plun;0.8 | 7.0 | ||
| JD222MY5V Y1 | 2200PF | 9.5 | 9.5&plun;0.8 | 7.0 | ||
| JD332MY5V Y1 | 3300PF | 11.0 | 9.5&plun;0.8 | 7.0 | ||
| JD392MY5V Y1 | 3900PF | 11.5 | 9.5&plun;0.8 | 7.0 | ||
| JD472MY5V Y1 | 4700PF | 13.0 | 9.5&plun;0.8 | 7.0 | ||
Dimensions and Tolerance TE：FS Cap.Chang Y5U Temperature Charaeristics B=3.0mm max for FS D=0.60mm &plun;0.05mm F=7.5 of 9.5 or 12.5 &plun;0.8mm L=3～33mm●according as customer,s requt and size.
■Approved/Recognized Te
| Related Standard | Certificate . | Approved Mogram | |
| CSA(Canada) | CSA-22.2 | E187963 |  |
| UL(USA) | UL1414 | ||
| VDE(Germany) | EN 132 400/IEC 60384-14 (VDE 0565 Teil 1-1) | 137027 |  |
| SEMKO(Sweden) | EN 132 400/IEC 60384-14 | 312302 |  |
| SEV(Switzerland) | EN 132 400/IEC 60384-14 | 03.1244 |  |
| FIMKO(Finland) | EN 132 400/IEC 60384-14 | FI 17334 A1 |  |
| NEMKO(rway) | EN 132 400/IEC 60384-14 | P |  |
| DEMKO(Denmark) | EN 132 400/IEC 60384-14 | 136122-01/A-01 |  |
| VDE CB | IEC 60384-14Table II 2nd(1993) | DE 1-30022 |  |
| CQC(China) | GB/T14472-1998 | CQC |  |
| EK(Korea) | K60384-14 | SZ03002-6002 |  |
AC.CAPACITORS(Y2：250VAC AND 300VAC)■Applications●For use in ciruit where alternating,pulsating,intermittent and steady high voltager exist.■Specifications
| Operating Temp.Rang | -25℃ to +85℃ | |||||||
| Rated Voltage | Applicable Standards | X1 | Y2 | |||||
| CSA,UL | 250VAC | |||||||
| SEMKO,SEV,FIMKO,CHINA,KOREA NEMKO,DEMKO,VDE(0565 Teil 1-1) | 400VAC | 300VAC | ||||||
| Dieleric Withstanding Voltage | Rated Voltage | Tt Voltage | ||||||
| 250VAC 300VAC | 1500VAC for 1 min 2600VAC for 1 min | |||||||
| Capacitance | Range | 10pf to10000pf、measured at 1KHz &plun;10%、1.0-5.0Vrms、25℃ | ||||||
| Dissipation Faor (D.F) | Y5P | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | ||||||
| Y5U | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | |||||||
| Y5V | TANδ≤5.0%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | |||||||
| Insulation Ristance | 10000MΩ at 500VDC for 1 minute. | |||||||
| Temperature Charaeristics | Te Code | Tolerance | Cap.Change | Temp.Range | ||||
| Y5P | &plun;10% | +10%、-10% max. | -25℃ to +85℃ | |||||
| Y5U | &plun;10%、&plun;20% | +22%、-56% max. | -25℃ to +85℃ | |||||
| Y5V | &plun;20% | +30%、-80% max. | -25℃ to +85℃ | |||||
| The reference temperature: 25℃ | ||||||||
Y2 SERI■INTRODUIONThe Ceramic Disc Capacitors are specifically digned for AC applications and meet the safety requirements of various safety standards agenci.The capacitors are ideal for across the line and line by-p applications■FEATUR●Ideal for across the line applications ●Compa size ●Cost effeive produ ●Safety standards recognized for AC applications■Part Nuer ConfigurationJY 102 K Y5P Y2 ①AC capacitors,safety ④Te code:Y5P,Y5U,Y5V ① ② ③ ④ ⑤ ②Rated capacitance ⑤Cl Y2 ③Tolerance on rated capacitance■CAPACITANCE AND DIMENSIONSWhere ordering safety standard recognized ceramic capacitors please use the part nuers as ted above
Rated Y2,X1：AC250V AND AC300V Dieleric strength：1500VAC/2600VAC
| PART NUER | T.C. | CAP. | TOL. | DIMENSION(mm) | ||
| D(max) | F | T(max) | ||||
| JY10KY5P Y2 To JY82KY5P Y2 | &plun;10% (Y5P) | 10PF to 82PF | K &plun;10% | 6.5 | 7.5&plun;0.8 | 5.0 |
| JY101KY5P Y2 | 100PF | 6.5 | 7.5&plun;0.8 | 5.0 | ||
| JY151KY5P Y2 | 150PF | 6.5 | 7.5&plun;0.8 | 5.0 | ||
| JY221KY5P Y2 | 220PF | 6.5 | 7.5&plun;0.8 | 5.0 | ||
| JY271KY5P Y2 | 270PF | 6.5 | 7.5&plun;0.8 | 5.0 | ||
| JY331KY5P Y2 | 330PF | 6.5 | 7.5&plun;0.8 | 5.0 | ||
| JY471KY5P Y2 | 470PF | 7.5 | 7.5&plun;0.8 | 5.0 | ||
| JY561KY5P Y2 | 560PF | 7.5 | 7.5&plun;0.8 | 5.0 | ||
| JY681KY5P Y2 | 680PF | 7.5 | 7.5&plun;0.8 | 5.0 | ||
| JY102KY5P Y2 | 1000PF | 8.5 | 7.5&plun;0.8 | 5.0 | ||
| JY471KY5U Y2 | +22～-56% (Y5U) | 470PF | K &plun;10% | 6.5 | 7.5&plun;0.8 | 5.0 |
| JY561KY5U Y2 | 560PF | 7.5 | 7.5&plun;0.8 | 5.0 | ||
| JY681KY5U Y2 | 680PF | 7.5 | 7.5&plun;0.8 | 5.0 | ||
| JY102MY5U Y2 | 1000PF | M &plun;20% | 7.5 | 7.5&plun;0.8 | 5.0 | |
| JY222MY5U Y2 | 2200PF | 9.5 | 7.5&plun;0.8 | 5.0 | ||
| JY332MY5U Y2 | 3300PF | 11.0 | 7.5&plun;0.8 | 5.0 | ||
| JY472MY5U Y2 | 4700PF | 13.0 | 7.5&plun;0.8 | 5.0 | ||
| JY102MY5V Y2 | +30～-80% (Y5V) | 1000PF | M &plun;20% | 6.5 | 7.5&plun;0.8 | 5.0 |
| JY152MY5V Y2 | 1500PF | 7.5 | 7.5&plun;0.8 | 5.0 | ||
| JY222MY5V Y2 | 2200PF | 7.5 | 7.5&plun;0.8 | 5.0 | ||
| JY332MY5V Y2 | 3300PF | 9.0 | 7.5&plun;0.8 | 5.0 | ||
| JY392MY5V Y2 | 3900PF | 10.5 | 7.5&plun;0.8 | 5.0 | ||
| JY472MY5V Y2 | 4700PF | 10.5 | 7.5&plun;0.8 | 5.0 | ||
| JY562MY5V Y2 | 5600PF | 11.5 | 7.5&plun;0.8 | 5.0 | ||
| JY682MY5V Y2 | 6800PF | 11.5 | 7.5&plun;0.8 | 5.0 | ||
| JY822MY5V Y2 | 8200PF | 12.5 | 7.5&plun;0.8 | 5.0 | ||
| JY103MY5V Y2 | 10000PF | 14.5 | 9.5&plun;0.8 | 5.0 | ||
Dimensions and Tolerance TE：FS Cap.Chang Y5V Temperature Charaeristics B=3.0mm max for FS D=0.60mm &plun;0.05mm F=6.35 of 7.5 or 9.5 &plun;0.8mm L=3～33mm●according as customer,s requt and size.
■Approved/Recognized Te
| Related Standard | Certificate . | Approved Mogram | |
| CSA(Canada) | CSA-22.2 -94 | LR 111243-1 |  |
| UL(USA) | UL1414 | E187963 |  |
| VDE(Germany) | EN 132 400/IEC 60384-14 (VDE 0565 Teil 1-1) | 123326 |  |
| SEMKO(Sweden) | EN 132 400/IEC 60384-14 | 312302 |  |
| SEV(Switzerland) | EN 132 400/IEC 60384-14 | 03.1245 |  |
| FIMKO(Finland) | EN 132 400/IEC 60384-14 | FI 153165 A1 |  |
| NEMKO(rway) | EN 132 400/IEC 60384-14 | P |  |
| DEMKO(Denmark) | EN 132 400/IEC 60384-14 | 135948-01/A-01 |  |
| VDE CB | IEC 60384-14Table II 2ND(1993) | DE 1-07488-A1 |  |
| CQC(China) | GB/T14472-1998 | CQC |  |
| EK(Korea) | K60384-14 | SZ03002-6001 |  |
AC.CAPACITORSApproved/Recognized Te■TE：Y1
| Related Standard | Certificate . | Approved mogram | |
| VDE (Germany) | EN132400/IEC60384-14 (VDE 0565 Teil 1-1) |  | |
| VDE CB | IEC 60384-14 Table II 2nd(1993) | DE 1-34062 |  |
■Specifications
| Rated Voltage | Applicable Standards | Rated voltage(Y1) | Tt Voltage | ||||
| VDE(0565 Teil 1-1) | 250V.AC | 400VAC for 1 min | |||||
| Capacitance | Range | 100pf to 4700pf、measured at 1HKz&plun;10%、1.0～5.0Vrms、25℃ | |||||
| Dissipation Faor(D.F) | Y5P | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | |||||
| Y5U | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | ||||||
| Insulation Ristance（IR） | 10000MΩ at 500VDC for 1 minute. | ||||||
| Temperature Charaeristics | Te Code | Tolerance | Cap.Change | Temp.Range | |||
| Y5P | &plun;10% | +10%、-10% max. | -30℃ to +125℃ | ||||
| Y5U | &plun;20% | +22%、-56% max. | -30℃ to +125℃ | ||||
| The reference temperature: 25℃ | |||||||
■Rated Y1：AC250V Dieleric strength： 4000VAC
| PART NUER | T.C. | CAP. | TOL. | DIMENSION(mm) | ||
| D(max) | F | T(max) | ||||
| JD101KY5P Y1 | &plun;10% (Y5P) | 100PF | K &plun;10% | 7 | 9.5&plun;0.8 | 7.0 |
| JD151KY5P Y1 | 150PF | 7 | 9.5&plun;0.8 | 7.0 | ||
| JD221KY5P Y1 | 220PF | 7 | 9.5&plun;0.8 | 7.0 | ||
| JD271KY5P Y1 | 270PF | 7 | 9.5&plun;0.8 | 7.0 | ||
| JD331KY5P Y1 | 330PF | 8 | 9.5&plun;0.8 | 7.0 | ||
| JD471KY5P Y1 | 470PF | 9 | 9.5&plun;0.8 | 7.0 | ||
| JD561KY5P Y1 | 560PF | 9 | 9.5&plun;0.8 | 7.0 | ||
| JD681KY5P Y1 | 680PF | 10 | 9.5&plun;0.8 | 7.0 | ||
| JD102KY5P Y1 | 1000PF | 11 | 9.5&plun;0.8 | 7.0 | ||
| JD102MY5U Y1 | +22～-56% (Y5U) | 1000PF | M &plun;20% | 11 | 9.5&plun;0.8 | 7.0 |
| JD152MY5U Y1 | 1500PF | 14 | 9.5&plun;0.8 | 7.0 | ||
| JD222MY5U Y1 | 2200PF | 16 | 9.5&plun;0.8 | 7.0 | ||
| JD252MY5U Y1 | 2500PF | 17 | 9.5&plun;0.8 | 7.0 | ||
| JD272MY5U Y1 | 2700PF | 17 | 9.5&plun;0.8 | 7.0 | ||
| JD332MY5U Y1 | 3300PF | 20 | 9.5&plun;0.8 | 7.0 | ||
| JD392MY5U Y1 | 3900PF | 20 | 9.5&plun;0.8 | 7.0 | ||
| JD472MY5U Y1 | 4700PF | 22 | 9.5&plun;0.8 | 7.0 | ||
Dimensions and Tolerance TE：FS B=3.0mm max for FS D=0.60mm &plun;0.05mm F=7.5 of 9.5 or 12.5 &plun;0.8mm L=3～33mm AC.CAPACITORSApproved/Recognized Te■TE：Y2
| Related Standard | Certificate . | Approved mogram | |
| VDE (Germany) | EN132400/IEC60384-14 (VDE 0565 Teil 1-1) |  | |
| VDE CB | IEC 60384-14 Table II 2nd(1993) | DE 1-33694 |  |
■Specifications
| Rated Voltage | Applicable Standards | Rated voltage(Y2) | Tt Voltage | ||||
| VDE(0565 Teil 1-1) | 250VA.C | 1500VAC for 1 min | |||||
| Capacitance | Range | 100pf to 4700pf、measured at 1HKz&plun;10%、1.0～5.0Vrms、25℃ | |||||
| Dissipation Faor(D.F) | Y5P | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | |||||
| Y5U | TANδ≤2.5%、measured at 1HKz&plun;10%、1.0-5.0Vrms、25℃ | ||||||
| Insulation Ristance（IR） | 10000MΩ at 500VDC for 1 minute. | ||||||
| Temperature Charaeristics | Te Code | Tolerance | Cap.Change | Temp.Range | |||
| Y5P | &plun;10% | +10%、-10% max. | -30℃ to +125℃ | ||||
| Y5U | &plun;20% | +22%、-56% max. | -30℃ to +125℃ | ||||
| The reference temperature: 25℃ | |||||||
■Rated Y1：AC250V Dieleric strength： 1500VAC
| PART NUER | T.C. | CAP. | TOL. | DIMENSION(mm) | ||
| D(max) | F | T(max) | ||||
| JY101KY5P Y2 | &plun;10% (Y5P) | 100PF | K &plun;10% | 7 | 7.5&plun;0.8 | 6.0 |
| JY151KY5P Y2 | 150PF | 7 | 7.5&plun;0.8 | 6.0 | ||
| JY221KY5P Y2 | 220PF | 7 | 7.5&plun;0.8 | 6.0 | ||
| JY271KY5P Y2 | 270PF | 7 | 7.5&plun;0.8 | 6.0 | ||
| JY331KY5P Y2 | 330PF | 7 | 7.5&plun;0.8 | 6.0 | ||
| JY471KY5P Y2 | 470PF | 7 | 7.5&plun;0.8 | 6.0 | ||
| JY561KY5P Y2 | 560PF | 8 | 7.5&plun;0.8 | 6.0 | ||
| JY681KY5P Y2 | 680PF | 8 | 7.5&plun;0.8 | 6.0 | ||
| JY102KY5P Y2 | 1000PF | 9 | 7.5&plun;0.8 | 6.0 | ||
| JY102MY5U Y2 | +22～-56% (Y5U) | 1000PF | M &plun;20% | 10.5 | 7.5&plun;0.8 | 6.0 |
| JY152MY5U Y2 | 1500PF | 12 | 7.5&plun;0.8 | 6.0 | ||
| JY222MY5U Y2 | 2200PF | 14 | 7.5&plun;0.8 | 6.0 | ||
| JY252MY5U Y2 | 2500PF | 15 | 7.5&plun;0.8 | 6.0 | ||
| JY272MY5U Y2 | 2700PF | 15 | 7.5&plun;0.8 | 6.0 | ||
| JY332MY5U Y2 | 3300PF | 27 | 7.5&plun;0.8 | 6.0 | ||
| JY392MY5U Y2 | 3900PF | 18 | 7.5&plun;0.8 | 6.0 | ||
| JY472MY5U Y2 | 4700PF | 18 | 7.5&plun;0.8 | 6.0 | ||
Dimensions and Tolerance TE：FS B=3.0mm max for FS D=0.60mm &plun;0.05mm F=6.35 of 7.5 or 9.5 &plun;0.8mm
L=3～33mm
■Marking requt the same as follows
4700PF/250VAC: 2200PF/400VAC:
