- 企业类型:贸易商
- 新旧程度:全新
品名:PR655色温照度计
型号:PR655
详细介绍 特点: 便携式,锂电池供电。采用触摸彩屏。可直接显示光谱。SD卡存储。快速扫描128位探测器。低成本高光谱测试仪器。主要用途: LCD背光测试、OLED光电性能分析。各种光源的亮度、色度、色温、光谱测试。反射系数和透过率测试。 光传感器 128个探测器阵列 功能描述 PR-655光谱光度/色度/辐射度计
* 光谱范围:380nm-780nm
* 可测量LED/LCD等各类显示器及在一定频率下发光的发光体
* 亮度,色温,色差,照度,辐射度,显色指数,色差等参数
* 与稳流电源配合,更可测量OLED 等的电学特性
* 全彩触摸屏显示器
* 宽动态范围:可满足任何显示器测量要求
* 可充电锂电池(可连续工作12小时):适用于野外操作
* SD存储卡:可存储几千条测量数据
品名:色彩照度计CL-200 型号:CL-200 详细介绍 色彩照度计CL-200可对光源的三刺激值、色度、色差、相关色温、照度(JIS普通型AA级)进行测量。 功能描述 scriptionBlock01">
主要用途
scriptionContents">- 投影光源的研究领域
- CRT、彩色液晶显示质量的管理。
- 检查辉度箱的色彩经时变化。
- 荧光灯接合器的研究领域、质量管理
- 对色彩检查用照明盒的管理
- 建筑、室内照明的研究领域
- 心理学实验场景的检查。
scriptionBlock01">
主要特征
scriptionContents">可通过4种校正功能修正测定值。
可通过4种校正功能修正测定值。
常规校正:将标准光源A设定为校正光源,修改测定值。
常规用户校正:输入校正光源值,修改测定值。
多点校正:根据超高压水银灯的R G B W值修改测定值。
多点用户校正:输入校正光源R G B W值,修改测定值。
※输入多点用户校正修改值时,需要使用另售的数据管理软件CL-S1w。
受光部将不留偏差自动调整到“0”。
只要打开电源,受光部即可不留偏差地自动调整为“0”(0校正),可迅速开始测量作业。
拆分的本体和受光部可通过市场销售的普通LAN电缆连接。
对远离本体的测量物,可以通过放置受光部的方式实现远距离测量,长可达(100m)。
※使用另售的配件——本体连接器T-A20、受光部连接器T-A21时
可通过RS-232C实现双向通信。
由于是RS-232标准装置,所以可与计算机直接连接实施数据处理。可在实施了多点测定的情况下,统一处理多个受光部的测定数据。
※为实现RS-232C通信,备有另售的配件——连接电缆T-A11。
可输出打印。
可连接到市场销售的(RS-232标准)等普通打印机上,输出测量的数据。
※作为输出打印用的另售配件,还备有打印电缆T-A12。
采用清晰快捷的按键遮盖操作。
虽然功能较多,但平时不使用的按键可通过上下滑动的按键遮盖予以隐藏,这样就可以轻松快捷地操作,避免出现误操作。
LCD后灯将自动点亮。(低照度、同步时)
电源可使用单3电池或AC适配器(另售)。
使用方便、廉价,可进行多点(多30点)测量。
一台采用液晶显示或按键操作的本体多可连接30点的受光部。
在进行多点测量时,需要使用另售配件即本体连接器T-A20、受光部连接器T-A21。
系统结构充实完备专用PC软件。
另售的附属软件——数据管理软件CL-S1w,可进行诸如实时显示测定值、多可进行30点的多点测量管理、ANSI测量间隔设定、基准值上限值/下限值等设定。
型号:CL200A
详细介绍 适用于照明光源,特别是一些新型的发光源,如发光二极管(LED)照明和有机电致发光(Organic EL)照明 色彩照度计用于测量光源的三刺激值、色度、色差、相关色温及照度。 功能描述
规格
CL-200A 规格表
型号 | CL-200A |
---|---|
亮度等级 | 符合JIS C1609-1:2006的AA等级,照度部分:常规测量仪器 |
相关光谱敏感度 | 与CIE 标准观察者曲线极其吻合 与光谱视觉效率函数的误差小于6%(f1’) |
余弦修正 (f2) | Ev:小于3% |
传感器 | 硅光元件 |
测量功能 | 三刺激值:XYZ 色度值:Evxy;Evu’v’;Ev;特征波长,色纯度 相关色温:EvTcp uv;Tcp(JIS 法:仅连接CL-S10w时有效) 色差:(XYZ),(Evxy),(Evu’v’),Evu’v’(标准值:1) |
其他功能 | 用户校准,数据保持,多点测量(2-30个点) |
测量范围 | 0.1-99,990 lx,0.01-9,999 fcd 色度:(5 lx,0.5 fcd以上)四档范围自动切换 |
Ev (线性):显示值的±2%±1位小数 xy:±0.002 (800 lx,标准光源A) | |
重复性 | Ev:±0.5%+1位小数(2δ) xy:±0.0005 (800 lx,标准光源A) |
温度偏差 | Ev:显示值的±3%±1位小数 xy:±0.003(基于柯尼卡美能达标准) |
湿度偏差 | Ev:显示值的±3%±1位小数 xy:±0.003(基于柯尼卡美能达标准) |
响应时间 | 0.5秒(连续测量) |
数字输出 | USB |
显示 | 4位有效数字,LCD背光照明显示 |
操作温度/湿度范围 | -10-40°C,相对湿度85%以下(35°C时),无凝露 |
储存温度/湿度范围 | -25-55°C,相对湿度85%以下(35°C时),无凝露 |
电源 | 2节五号电池/电源适配器(可选配件) |
电池寿命 | 72小时以上(使用碱性电池,连续测量时) |
尺寸 | 69×174×35mm |
重量 | 215g(不含电池) |
标准配件 | 保护套T-A10,探头盖T-A13,腕带,五号电池(2节)※, 数据管理软件CL-S10w,USB连接线 T-A15 ※ 一些情况下不作为标准配件 |
可选配件 | 测量探头,主机适配器T-A20,探头适配器T-A21, 外接电源适配器AC-A308(1-10个探头) 外接电源适配器AC-A311(1-30个探头) 打印连接线T-A12,橡胶套CL-A11,外箱CL-A10 |
数据管理软件CL-S10w规格表
型号 | CL-S10w(内置Excel?) |
---|---|
系统要求 | 需要安装以下系统之一: Windows? XP+ Excel? 2003(英语,日语或简体中文) Windows? 7+ Excel? 2007(英语,日语或简体中文) ※以上系统的详细硬件安装要求请参考相关规格表。 ※括号中的语言指的是操作系统语言版本 |
适用仪器 | CL-200A,CL-200※ ※使用CL-200时一些功能无法实现 |
产品介绍
小巧,方便携带
CL-200A的机身非常小巧轻便,可以贴合你的双手。仪器可用电池供电,方便您随身携带并且可以在现场使用。
可拆卸的测量探头
品名:数字式照度计
型号:TES-1330A/1332A/1334A
详细介绍 MODEL TES-1330A/1332A/1334A 准确度高及反应速度快 3 1/2位液晶显示 输出可外接记录器(TES-1332A/1334A) 读值锁定功能, 峰值锁定(1334A) 功能描述规 格 TES-1330A/1332A/1334A
显示器 | 3 1/2位液晶显示 |
测量范围 | 20/200/2000/20000 Lux (1330 also Footcandle for 1334A) 200/2000/20000/200000 Lux (1332A) 20000 lux-reading x 10; 200000 lux-reading x 100 |
过载显示 | Hightest digit of (1) is displayed |
分辨率 | 0.01 Lux(1330A,1334A) & 0.1 Lux(1332A) |
准确度 | ±3% rdg ± 0.5% f.s.(<10,000 lux) ±4% rdg ± 10dgts (>10,000 lux) (以色温2856 K标准平面灯校正) |
重复测试 | ±2% |
温度特性 | ±0.1% /℃ |
取样率 | Approx. 2 times/sec. |
记录器输出 | DC 2V/f.s. (满刻度) (TES-1332A) |
操作及储存温湿度 | 0°to 40℃ (32℉ to 104℉) < 70% R.H. |
电源 | one 9V battery |
光检测器尺寸 | 100mm(L) x 60mm(W) x 27mm(H) |
电表尺寸 | 135mm(L) x 72mm(W) x 33mm(H) |
重量 | 250g |
附件 | 使用说明书,皮盒,9V电池 |
型号: TES-1335
详细介绍 MODEL TES-1335 光谱反应符合国际照明协会CIE标准。 峰值锁定功能。 量测范围0到40K Lux (0到40K fc)。 相对值比较功能。 准确度高及反应速度快。 入射光余弦角度自动补正功能。 读值锁定功能。 30分钟自动关机功能。 值及小值量测功能。 CNS5119 AA级。 功能描述规 格 TES-1335
显示 | 3-3/4位液晶显示及模拟条形码指示 |
测量档位 | 40.00Lux、400.0Lux、4000Lux、40.00KLux、400.0KLux、40.00fc、400.0fc、4000fc、40.00Kfc |
过载显示 | 显示“OL” |
分辨率 | 0.01 Lux (0.01fc) |
准确度 | ±3%rdg ± 0.5% f.s (大于10KLux档准确度为 ±4%rdg ±10dgts, 以色温2856K标准平面灯校正。 |
光谱准确性 | f ’1 < 6% |
温度特性 | ±0.1% 1℃ |
取样率 | 数字显示每秒1.3次,模拟显示每秒13.3次 |
感光体 | 硅制光二极管及泸光镜片 |
操作 / 储存温湿度 | 0℃ ~ 40℃,80%R.H.以下 -10℃ ~ 50℃,70%R.H.以下 |
电源 | 6颗1.5V AAA电池 |
电池寿命 | 连续使用约400小时 (碳锌电池) |
光检测器引线长度及尺寸 | 150公分及92(长) × 60(宽) × 29mm(高) |
电表尺寸/ 重量 | 150(长) × 72(宽) × 35 mm (高) / 320g |
附件 | 说明书、电池、皮套 |
品名:数字式照度计
型号:TES-1336A
详细介绍 MODEL TES-1336A 可测量0~20000 Lux/Fc 可测量光强度 RS-232接口可与计算机联机 功能描述 规 格 TES-1336A显示 | 3 1/2 位液晶显示器 |
测量档位 | 20, 200, 2000, 20000 Lux/Fc (1Fc=10.76 Lux) |
过载显示 | 显示“OL” |
分辨率 | 0.01 Lux (0.01fc) |
准确度 | ±(3%rdg + 5dgts) |
重复测试 | ±2% |
温度特性 | ±0.1%/℃ |
取样率 | 2.5次/秒 |
感光体 | 光二极管 |
记录组数 | 多255组 |
记录笔数 | 16000笔 |
RS-232传输速率 | 9600bps |
操作温湿度 | 0℃~40℃ ( 32℉ ~ 104℉ ), 10~80%RH |
储存温湿度 | 10℃~60℃ ( 14℉ ~ 140℉ ), 10~70%RH |
电 源 | 单个 9V 电池,型式006P 或 IEC6F22 或 NEDA 1604 |
电池寿命 | 连续使用约 50 小时 (碱性电池) |
光检测器引线长度 | 150cm |
光检测器尺寸 | 87.5 ( L )×60 ( W )×29 ( H ) mm |
电表尺寸 | 146 ( L )×70 ( W )×39 ( H) mm |
重 量 | 300克 |
附 件 | 使用说明书、皮套、电池、 RS-232连接线、9pin转25pin转接头 、程序磁盘片、调整棒 |
品名:1339级照度计
型号:TES-1339
详细介绍 MODEL TES-1339 0.01Lux分辨率 / 999,9位数读值 平均值测量 / 照度积分测量 光强度测量 可扣除杂散光之光源照度测量 时间设定自动锁定测量 独特之资料记录及读值功能 (50组) 特性: 4位数双显示LCD 明视函数光谱反应≦6% 测量范围自0.01Lux至999900 Lux、0.001fc至99990 fc,计5档自动换档 准确且反应迅速 积分式照度测量 发光强度测量 读值锁定功能 资料记忆及读取功能 参数值可设定供偏差值或百分比测量 背景涟波光线及发光照度(STRAY + LIGHT)测量 时间锁定功能 点平均功能 比较器功能 自动关机功能 符合CNS 5119 ClassⅡ标准 功能描述
规格:
|
品名:Gossen 照度计
型号:GX-LR-GO-4056B(MAVOLUX 5032 B)
详细介绍照度测量 Digital Luxmeters and Luminance meters classified according to DIN 5032-7 and CIE 69. Wide range of applications: for light technicians, for the control of light sources, street lights, lighting of work places, public buildings, sports facilties;for quality control and quality assurance in the manufacture of lamps and light sources; for light designers and architects; for measurements in agriculture and horticulture. Both MAVALUX types allow measuring very high light intensities (brightest daylight, head lights) without any additional accessories. Expecially the MAVOLUX 5032 B having an initial sensitivity of 0.01 lx allows measuring extremely low light intensities, such as emergency lighting. Most
品名:闪光灯照度计
型号:DIGISKY
详细介绍
Specification |
DIGISKY is the new handy and lightweight exposure meter in the GOSSEN range of products for flash light and ambient light. It is the big, well-arranged graphic display which permits a comfortable reading of the measured values. Designed for one-hand operating, the DIGISKY is equipped with a ring controller through which all functions may be selected very easily. |
Even functions for special tasks may be set individually by means of three pre-settings, which may be chosen according to the photographer requirements. All measuring values may be indicated in full, ? or 1/3 f-stops. The DIGISKY has a built-in remote radio trigger. |
TFT-LCD Colour Graphic display Even in dark ambience all measuring values may be read clearly. Well-arranged menu structure with every information at a glance. |
Comfortable Triggering of your Studio Lighting Up to 4 groups may be selected and triggered on 8 different radio frequencies. |
Individual Configuration Up to three profiles may be programmed and selected. |
Technichal Data | |
Light Sensor | two colour-corrected sbc silicon photo diodes |
Processing of Measuring Values | digital; repeat accuracy + 1 digit (=0.1EV) |
Incident Light Reading | diffuser characteristics adjustable to flat or spherical (180°) |
Reflected Light Reading | measuring angle 20° |
Ambient Light (when ISO 100/21°) |
Incident Light Reading EV -2.5 to +18 |
Flash Light (when ISO 100/21°) |
Incident Light Reading f/1.0 to f/90 |
Functions | Up to three user specific pre-settings possible, digital display, flash light measurements (cord/non-cord/remote trigger), readout of the share of ambient light, USB interface for meter updates and for the transfer of the user setting from the PC, overflow and underflow (for measurements and display), battery check, EV, correction values, displaying of position of the measuring head, memory of measuring values, radio channel and group, dynamic analogue scale (for measuring value correction in 1/10 stops) |
Film speeds | from ISO 3/6° to 16000/43° in 1° DIN |
Shutter speeds (standard values) | 1/8000s up to 60 min in 1/1 or ? or 1/3 f-stops |
Flash synch speeds | 1/1000 to 1 sec |
Apertures ambient light | f/1.0 to f/128 |
Apertures flash light | f/1.0 to f/90 |
Correction values | EV -9.9 to +9.9 |
Radio module | OFF, elinchrom SkyPort and Skyspeed, more manufacturers of flash lights to follow |
Radio groups | 1 to 4 ?ALL, A, B, C, D |
Radio channels | 1 to 8 |
Frequency channels | Channel 1: 2456 MHz Channel 2: 2458 MHz Channel 3: 2460 MHz Channel 4: 2462 MHz, Channel 5: 2469 MHz Channel 6: 2471 MHz Channel 7: 2473 MHz Channel 8: 2475 MHz |
Power supply | meter-specific rechargeable Lithium-Ion-battery |
Operating temperature range | -10°C to +50°C |
Storage temperature | -20°C to +60°C |
Dimensions | approx. 139 x 66 x 15 mm |
Weight (incl. rechargeable battery) | approx. 100 g |
品名:闪光灯照度计 型号:STARLITE 2 详细介绍
Specification |
This all-in-one meter provides a complete package of features for standard and for special requirements in a durable water-proof housing. |
Exposure meter for ambient and flash light |
CINE-Meter for photographic film manufacturers |
Meter for illumination intensities and luminances |
Reflected light measuring with 1°-measuring angle through the viewfinder |
Reflected light measuring with 5°-measuring angle through the viewfinder |
Incident light measuring with raised diffuser: measuring characteristics spherical |
Incident light measuring with lowered diffuser: measuring characteristics flat plane |
Technichal Data | |
Measurements modes | Continuos light and flash (analogue, digital) |
Light sensor | 2 color corrected silicon photo diodes |
Measuring angel | 1° and 5° |
Incident light | Adjustible to flat or spherical characteristics |
Reflected light | Viewfinder adjustable to 1° and 5° |
Meas. range ambient light at ISO 100/21° Incident light: Reflected light 1°/5°: |
EV - 2,5 to + 18 EV 2,0 to + 18 / EV 1 to + 18 |
Meas.range flash light at ISO 100/21° Incident light: Reflected light 1°/5°: |
f/1,0 to f/128 f/2,8 to f/128 / f/1,4 to f/128 |
Measuring data processing | digital |
Repeat accuracy | +/- 1 digit (= 0,1 EV) |
Film speeds | ISO 3,2/6° to ISO 8000/40° (in 1° DIN) |
Apertures | f/1,0 to f/128 |
Shutter speeds | 1/8000 s to 60 min. |
Flash sync speeds | 1 to 1/1000 s |
Multiple flash calculation | up to 9 flashes |
Cine speeds (f. p. s.) | 8-128B/s |
Photometry | lx, fc, cd/m2, fL, lxs, fcs, cds/m2, fLs |
Other read-outs | measuring function, outranging the measuring range |
Analogue scale | f/1,0 to f/128, Zone 0-X |
Corrections/Extension factors | EV -7.9 to + 7.5 / 1.0 to 240 |
Battery | 1,5 V (AA) or akku 1,2 V |
Dimensions | approx. 164 x 66 x 26 mm |
Weight (without battery) | approx. 185 g |
Accessories included | Bag, strap, battery, operating instructions |
