| 品牌 | oem | 型号 | LY-HY01102B |
| 类型 | 智能水表 | 结构形式 | 干式水表 |
| 等级 | B级 | 公称通径 | 15（mm） |
| 公称压力 | 1.6（MPa） | 分界流量 | 1.5（m3/h） |
| 工作温度 | 40（℃） | 刻度 | 00000 |
| 小读数 | 99999 |
For hot or cold water
Dry-dial,magnetic drive, protected against external magnetic tampering
Vacuum-sealed register, frost resistant, keeps clear reading for long time
Register can be rotated in any direction for convenient reading
Brass body optional
Brass body can be painted or nickel coated
High accuracy
m3 or gal, optional
Remote transmission device can be added upon request
Many kinds of sensors, such as Reed Switch, Hall and Weagand can be supplied upon request
Pulse output may be 10l/pulse
The meters conform to ISO4064 Standard Class B
The clockwork can be easily rotated over 360ºfor comfortable reading
Magnetic shield structure, with which the water meter can not be influenced by outside magnetic fields.
