| 品牌 | mshot | 型号 | MC20 |
| 分辨率 | 1360 x 1024（mm） | 放大倍率 | 1360 x 1024 |
| 操作方式 | 鼠标自动控制 |
Ease of operation, high resolution and excellent color reproduction are the distinguishing features of the MSHOT Camera MC20. Combining a 1.4 megapixels CCD sensor with an electronic shutter. The excellent sensitivity and low noise and high frames, supply an affordable choice to you. Applications for the MC20 include microscopy, fluorescence, label imaging, industrial inspection, GFP, H, NIR, FRET imaging, great for dark field, and DIC. Can connect to any standard trinocular microscope.
Features:
TheMSHOT®MC20camera with high-resolution 2/3〞 SONY EXview HAD CCD is a 1.4 megapixel,12-bit cooled dial color camera, offering low-noise imaging and rapid data transfer. Full-resolution images are displayed at an ultra-high 15 frames per second. The U2.0 interface produces fast transfer rates, standard C-Mount makes connection to any microscope easy. With its Optional Cooling Mechani, the MSHOT®MC20 can suppress thermal background noise and obtain high-contrast images when capturing fluorescence images that require long exposure times.
Specification:
Item | Specification | Item | Specification |
CCD chip | 2/3”sony HAD CCD | Readout noise | 8e- |
Resolution | 1360×1024 | Cable | U2.0 (480 Mbit / sec) |
Pixel size | 6.45μm x6.45μm | Power | U |
Frame rate | 15fps@ 1360×1024 | Electricity | ≈200 mA |
60 fps@ 640×480 | White balance | Manual/Auto One-touch | |
Shutter | Electronic | Integrate exposure | 1/44000s–115s.Auto |
S/N ratio | 72dB | Software | Display/Film/Video |
Scan mode | Continuous variable electronic shutter | Operating Tem | -10°C~ 75°C |
Connector | C-Mount |
