供应美国CSB铅酸免维护蓄电池12V 34AH
| 价 格： | 416.00 | |
| 型号/规格： | GP12340 | |
| 品牌/商标： | CSB |
| 规格书 |
| 局数 | 6 |
| 电压值 | 12 V |
| 安培数 | 34 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) |
| 重量(kg) | Approx. 10.48kg. (23.10 lbs.) |
| 放电电流5秒(A) | 380A (5sec.) |
| 内阻(mΩ) | Approx. 8.0 mΩ |
| 温度工作范围 | Discharge：-15℃~50℃(5°F~122°F) Charge：-15℃~40℃(5°F~104°F) Storage：-15℃~40℃(5°F~104°F) |
| 一般使用温度工作范围 | 25°C ± 3°C (77°F± 5°F) |
| 浮充使用充电条件 | 13.5 to 13.8 VDC/unit Average at 25°C (77°F) |
| 安培数/只 | 10.2A |
| 循环寿命测试条件 | 14.4 to 15.0 VDC/unit Average at 25°C (77°F) |
| 单一放电条件 | CSB Batteries can be stored for more than 6 months at 25°C (77°F) Please charge batteries before using. For higher temperatures the time interval will be shorter. |
| 端子 | B5-L terminal to accept M5 nut & bolt |
| 电槽组材质 | ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request. |
| 尺寸 |
| 定电流放电特性表 单位: 安培(25°C,77°F) |
| 终止电压/时间 | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 2HR | 3HR | 4HR | 5HR | 8HR | 10HR | 20HR |
| 1.60V | 144.33 | 91.67 | 69.33 | 42.08 | 25.00 | 14.50 | 10.28 | 8.00 | 6.55 | 4.26 | 3.48 | 1.86 |
| 1.67V | 128.23 | 85.48 | 65.50 | 41.26 | 24.73 | 14.40 | 10.15 | 7.96 | 6.50 | 4.23 | 3.43 | 1.78 |
| 1.70V | 121.33 | 82.83 | 63.80 | 40.83 | 24.50 | 14.30 | 10.10 | 7.95 | 6.49 | 4.23 | 3.41 | 1.75 |
| 1.75V | 109.66 | 77.54 | 61.20 | 40.00 | 24.37 | 14.20 | 10.00 | 7.93 | 6.47 | 4.18 | 3.35 | 1.69 |
| 1.80V | 98.00 | 72.25 | 58.75 | 39.17 | 24.00 | 14.10 | 9.91 | 7.89 | 6.45 | 4.14 | 3.30 | 1.64 |
| 1.85V | 86.33 | 66.96 | 55.71 | 38.17 | 23.58 | 14.04 | 9.81 | 7.84 | 6.43 | 4.09 | 3.24 | 1.58 |
| 定功率放电特性表 单位: 瓦特(25°C,77°F) |
| 终止电压/时间 | 5MIN | 10MIN | 15MIN | 30MIN | 1HR | 2HR | 3HR | 4HR | 5HR | 8HR | 10HR | 20HR |
| 1.60V | 1732.00 | 1100.00 | 832.00 | 505.00 | 300.00 | 174.00 | 124.00 | 96.00 | 78.60 | 51.10 | 41.70 | 21.60 |
| 1.67V | 1538.80 | 1025.80 | 788.00 | 495.10 | 296.80 | 172.50 | 122.60 | 95.79 | 78.11 | 50.82 | 41.14 | 20.69 |
| 1.70V | 1456.00 | 994.00 | 771.00 | 490.00 | 294.90 | 172.00 | 122.00 | 95.70 | 77.90 | 50.70 | 40.90 | 20.30 |
| 1.75V | 1316.00 | 930.50 | 739.00 | 480.60 | 291.70 | 171.00 | 121.00 | 95.20 | 77.65 | 50.15 | 40.25 | 19.60 |
| 1.80V | 1176.00 | 867.00 | 705.00 | 470.00 | 288.00 | 170.00 | 120.00 | 94.70 | 77.40 | 49.60 | 39.60 | 18.90 |
| 1.85V | 1036.00 | 803.50 | 668.50 | 458.00 | 283.00 | 168.50 | 119.00 | 94.20 | 77.15 | 49.05 | 38.95 | 18.20 |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 王坤
- 电话：0755-83794331
- 传真：0755-83794083
- 手机：13560791039
- QQ ：
供应美国CSB铅酸免维护蓄电池12V 26AH
信息内容：规格书 局数 6 电压值 12 V 安培数 26 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) 重量(kg) Approx. 8.45 kg. (18.63 lbs.) 放电电流5秒(A) 350 A (5sec.) 内阻(mΩ) Approx. 11 mΩ 温度工作范围 Discharge：-15℃~50℃(5°F~122°F)Charge：-15℃~40℃(5°F~104°F)Storage：-15℃~40℃(5°F~104°F) 一般使用温度工作范围 25°C ± 3°C (77°F ± 5°F) 浮充使用充电条件 13.5 to 13.8 VDC/unit Average at 25°C (77°F) 安培数/只 7.8 A 循环寿命测试条件 14.4 to 15.0 VDC/unit Average at 25°C (77°F) 单一放电条件 CSB Batteries can be stored for more than 6 months at 25°C (77°F) Please charge batteries before using. For higher temperatures the time interval will be shorter. 端子 B1/B3/B3B-L terminal to accept M5 nut & bolt 电槽组材质 ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request. 尺寸 ...
供应美国CSB铅酸免维护蓄电池12V 17AH
信息内容：规格书 局数 6 电压值 12 V 安培数 17 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) 重量(kg) Approx. 5.5 kg. (12.13 lbs.) 放电电流5秒(A) 230 A (5sec.) 内阻(mΩ) Approx. 16 mΩ 温度工作范围 Discharge：-15℃~50℃(5°F~122°F)Charge：-15℃~40℃(5°F~104°F)Storage：-15℃~40℃(5°F~104°F) 一般使用温度工作范围 25°C ± 3°C (77°F ± 5°F) 浮充使用充电条件 13.5 to 13.8 VDC/unit Average at 25°C (77°F) 安培数/只 5.1A 循环寿命测试条件 14.4 to 15.0 VDC/unit Average at 25°C (77°F) 单一放电条件 CSB Batteries can be stored for more than 6 months at 25°C (77°F) Please charge batteries before using. For higher temperatures the time interval will be shorter. 端子 B1/B3-L terminal to accept M5 nut & bolt 电槽组材质 ABS(UL94-HB/FileE50263)*Flammability resistance of(UL94-V0/File E54297) can be available upon request. 尺寸 定电流...
