单色液晶屏字符式点阵液晶模块1604
| 价 格： | 面议 | |
| 型号/规格： | 字符点阵 | |
| 品牌/商标： | 洪泰 |
| 产品型号 | 点阵数(列*行) | 外形尺寸 (mm) | 视域尺寸(mm) | 控制器 | 说明 |
| HTG1602A | 16*2 | 65.0*27.7 | 61.0*15.7 | NT7605 | COG 蓝膜 |
| HTG1603A | 16*3 | 39.0*25.5/20.0*2.0 | 35.0*17.0 | ST7036 |
COG 黄绿膜 |
| HTG1603B | 16*3 | 64.0*33.5/28.0*2.0 | 61.0*25.0 | ST7036 | COG 灰膜 |
| HTG1603C | 16*3 | 66.2*35.7 | 61.0*25.0 | ST7036 |
COG |
| HTG1604B | 16*4 | 64.8*38.1 | 61.0*27.2 | S6A0094 | COG |
| HTG2002B | 20*2 | 67.0*34.0 | 64.0*26.0 | NT7605 | COG |
| HTM0802A | 8*2 | 58.0*32.0 | 38.0*16.0 | ST7066U |
|
| HTM0802B | 8*2 | 58.0*32.0 | 38.0*16.0 | S6A0069 |
|
| HTM1601A | 16*1 | 80.0*36.0 | 64.5*13.5 | S6A0069 |
KS0066 |
| HTM1602-10 | 16*2 | 85.0*29.5 | 64.5*15.8 | S6A0069 |
|
| HTM1602-12 | 16×2 | 72.0×36.0 | 64.5*16.0 | S6A0069 |
|
| HTM1602-13 | 16*2 | 91.0*47.0 | 78.0*26.8 | S6A0069 |
|
| HTM1602-17 | 16*2 | 76.3*40.5 | 73.3*32.5 | S6A0069 |
|
| HTM1602-18 | 16*2 | 72.0*36.0 | 64.5*16.0 | S6A0069 |
|
| HTM1602-8 | 16*2 | 84.0*44.0 | 61.0*15.8 | S6A0069 |
|
| HTM1602-9 | 16*2 | 100.0*38.8 | 80.0*20.5 | S6A0069 |
|
| HTM1602A | 16*2 | 80.0*36.0 | 64.5*15.8 | S6A0069 |
|
| HTM1602B | 16*2 | 122.0*44.0 | 99.0*24.0 | S6A0069 |
|
| HTM1604A | 16*4 | 87.0*60.0 | 62.0*25.0 | S6A0069 |
|
| HTM2002A | 20*2 | 116.0*37.0 | 83.0*18.6 | S6A0069 |
|
| 产品型号 | 点阵数(列*行) | 外形尺寸 (mm) | 视域尺寸(mm) | 控制器 | 说明 |
| HTM2004-2 | 20*4 | 105.0*38.0 | 76.0*25.2 | S6A0069 |
|
| HTM2004-5 | 20*4 | 77.0*47.0 | 60.0*22.2 | S6A0069 |
|
| HTM2004A | 20*4 | 98.0*60.0 | 76.0*25.5 | S6A0069 |
|
| HTM4002A | 40*2 | 182.0*33.5 | 155.1*16.0 | S6A0069 |
|
| HTM4002B | 40*2 | 182.0*33.5 | 155.1*16.0 | S6A0069 |
|
| HTM4004A | 40*4 | 190.0*54.0 | 147.0*29.5 | S6A0069 |
|
| HTM4004B | 40*4 | 190.0*54.0 | 147.0*29.5 | S6A0069 |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 刘新剑
- 电话：0755-33671719-616
- 传真：0755-89667086
- 手机：13163779199
- QQ ：
供应 COG点阵低功耗液晶屏
信息内容：产品型号 点阵数(列*行) 外形尺寸 (mm) 视域尺寸(mm) 控制器 说明 HTG128128Z 128*128 48.9*57.6 39.6*46.0 SSD1848 4级灰度, 串并均可 HTG12832A 128*32 34.5*17.9 32.0*10.0 ST7565 并口 HTG12832F-3 128*32 63.0*27.5 59.0*17.5 ST7565R 并口 HTG12832L 128*32 35.0*17.9 32.0*10.0 ST7565 串并均可 HTG12848A 128*48 78.7*35.9 75.3*28.3 ST7565R 串并均可 HTG12864-20 128*64 53.2*37.8 45.0*27.0 ST7565 串并均可 HTG12864-55 128*64 28.55*20.1 26.15*13.9 ST7565R 串并均可 HTG12864-9 128*64 33.1*31.5 30.1*23.3 ST7565 串并均可 HTG12864C 128*64 39.0*31.1 36.0*23.5 ST7565 串并均可 HTG12864D 128*64 31.0*27.0 28.0*18.0 ST7565 并口 HTG12864I 128*64 69.1*50.0 65.5*38.0 S6B0724 串并均可 HTG12864K1 128*64 89.8*54.6 70.7*38.8...
