供应FRG系列保险丝
| 价 格： | 面议 | |
| 型号/规格： | FRG | |
| 品牌/商标： | 进口 |
| Part Number |
Hold Current |
Trip Current |
Max.Time to Trip |
Maximum Current |
Rated Voltage |
Typical Power |
Resistance Tolerance | |
| RMIN | R1MAX | |||||||
| IH, A | IT, A | at 5xIH | IMAX, A | VMAX,Vdc | Pd, W | ohms | ohms | |
| FRG300-16F | 3.0 | 5.1 | 2.0 | 100 | 16 | 2.3 | 0.034 | 0.105 |
| FRG400-16F | 4.0 | 6.8 | 3.5 | 100 | 16 | 2.4 | 0.020 | 0.063 |
| FRG500-16F | 5.0 | 8.5 | 3.6 | 100 | 16 | 2.6 | 0.014 | 0.044 |
| FRG600-16F | 6.0 | 10.2 | 5.8 | 100 | 16 | 2.8 | 0.009 | 0.033 |
| FRG700-16F | 7.0 | 11.9 | 8.0 | 100 | 16 | 3.0 | 0.006 | 0.021 |
| FRG800-16F | 8.0 | 13.6 | 9.0 | 100 | 16 | 3.0 | 0.005 | 0.018 |
| FRG900-16F | 9.0 | 15.3 | 12.0 | 100 | 16 | 3.3 | 0.004 | 0.015 |
| FRG1000-16F | 10.0 | 17.0 | 12.5 | 100 | 16 | 3.3 | 0.003 | 0.012 |
| FRG1100-16F | 11.0 | 18.7 | 13.5 | 100 | 16 | 3.7 | 0.003 | 0.010 |
| FRG1200-16F | 12.0 | 20.4 | 16.0 | 100 | 16 | 4.2 | 0.002 | 0.009 |
| FRG1400-16F | 14.0 | 23.8 | 20.0 | 100 | 16 | 4.6 | 0.002 | 0.008 |
| ||||||||||||||||||||||||||||||||||||||||||||
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 销售部
- 电话：0755-83350996
- 传真：0755-82883405
- 手机：18025309119
- QQ ：
供应FRH系列保险丝
信息内容：PartNumber HoldCurrent MaximumCurrent Max Oper.Voltage Max Int.Voltage Resistance Tolerance RMIN R1MAX IH, A IMAX, A VMAX,V VIMAX, V ohms ohms FRH080-250UF 0.08 3.0 60 250 14.0 33.0 FRH080-250F 0.08 3.0 60 250 14.0 33.0 FRH110-250UF 0.11 3.0 60 250 5.0 16.0 FRH110-250F 0.11 3.0 60 250 5.0 16.0 FRH120-250UF 0.12 3.0 60 250 6.0 16.0 FRH120-250F 0.12 3.0 60 250 4.0 16.0 FRH145-250UF 0.15 3.0 60 250 3.5 12.0 FRH145-250F 0.15 3.0 60 250 3.0 12.0 FRH180-250UF 0.18 10 60 250 0.8 4.0 FRH180-250F 0.18 10 60 250 0.8 4.0 FRH150-600F 0.15 3.0 60 600 6.0 22.0 FRH160-600F 0.16 3.0 60 600 4.0 18.0 P/N Pcs /Bag Reel/Tape FRH080-250UF 300 1.5K FRH080-250F 300 1.5K FRH110-250UF 300 1.5K FRH110-250F 300 1.5K FRH120-250UF 300 1.5K FRH120-250F 300 1.5K P/N Pcs /Bag Reel/Tape FRH145-250UF 30...
供应FRVL系列保险丝
信息内容：PartNumberM HoldCurrent TripCurrent Max.Timeto Trip MaximumCurrent RatedVoltage TypicalPower Resistance Tolerance RMIN R1MAX IH, A IT, A at 5xIH IMAX, A VMAX,Vdc Pd, W ohms ohms FRVL010-120F 0.10 0.20 10.0 2.0 120 0.84 3.00 7.50 FRVL017-120F 0.17 0.34 10.0 2.0 120 0.84 2.00 7.00 FRVL020-120F 0.20 0.40 9.0 2.0 120 1.08 1.83 4.40 FRVL025-120F 0.25 0.50 7.5 3.0 120 1.08 1.25 3.00 FRVL030-120F 0.30 0.60 8.5 3.0 120 1.44 0.88 2.10 FRVL040-120F 0.40 0.80 6.5 3.0 120 1.44 0.55 1.29 FRVL050-120F 0.50 1.00 6.0 3.0 120 1.56 0.50 1.17 FRVL065-120F 0.65 1.30 5.7 5.0 120 1.68 0.31 0.72 FRVL070-120F 0.75 1.50 6.3 5.0 120 1.80 0.25 0.60 FRVL075-120F 0.75 1.50 15.0 7.5 120 2.64 0.25 0.69 ...
