供应FSMD1210保险丝
| 价 格： | 面议 | |
| 型号/规格： | FSMD1210 | |
| 品牌/商标： | 进口 |
| Part Number |
Hold Current |
Trip Current |
Rated Voltage |
Maximum Current |
Typical Power |
Max Time to Trip | Resistance Tolerance | ||
| RMIN | R1MAX | ||||||||
| IH, A | IT, A | VMAX,Vdc | IMAX, A | Pd, W | Current | Time | ohms | ohms | |
| FSMD005-1210 | 0.05 | 0.15 | 60 | 10 | 0.60 | 0.25 | 1.50 | 3.60 | 50 |
| FSMD010-1210 | 0.10 | 0.25 | 60 | 10 | 0.60 | 0.50 | 1.50 | 2.10 | 15 |
| FSMD020-1210 | 0.20 | 0.40 | 30 | 10 | 0.60 | 8.00 | 0.02 | 0.80 | 5.0 |
| FSMD035-1210 | 0.35 | 0.70 | 20 | 40 | 0.60 | 8.00 | 0.20 | 0.32 | 1.3 |
| FSMD050-1210 | 0.50 | 1.00 | 16 | 40 | 0.60 | 8.00 | 0.10 | 0.25 | 0.9 |
| FSMD075-1210 | 0.75 | 1.50 | 8 | 40 | 0.60 | 8.00 | 0.10 | 0.13 | 0.4 |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 销售部
- 电话：0755-83350996
- 传真：0755-82883405
- 手机：18025309119
- QQ ：
供应FSMD2920系列保险丝
信息内容：PartNumber HoldCurrent TripCurrent RatedVoltage MaximumCurrent TypicalPower Max Time to Trip Resistance Tolerance RMIN R1MAX IH, A IT, A VMAX,Vdc IMAX, A Pd, W Current Time ohms ohms FSMD030-2920 0.30 0.60 60 10 1.5 1.5 3.0 1.00 4.80 FSMD050-2920 0.50 1.00 60 10 1.5 2.5 4.0 0.30 1.40 FSMD075-2920 0.75 1.50 33 40 1.5 8.0 0.3 0.18 1.00 FSMD100-2920 1.10 2.20 33 40 1.5 8.0 0.5 0.09 0.41 FSMD125-2920 1.25 2.50 33 40 1.5 8.0 2.0 0.05 0.25 FSMD150-2920 1.50 3.00 33 40 1.5 8.0 2.0 0.05 0.23 FSMD185-2920 1.85 3.70 33 40 1.5 8.0 2.5 0.04 0.15 FSMD200-2920 2.00 4.00 16 40 1.5 8.0 4.5 0.035 0.120 FSMD250-2920 2.50 5.00 16 40 1.5 8.0 16 0.025 0.085 ...
供应FLR系列保险丝
信息内容：PartNumber HoldCurrent TripCurrent RatedVoltage MaximumCurrent TypicalPower Resistance Tolerance RMIN RMAX R1MAX IH, A IT, A VMAX,Vdc IMAX, A Pd, W ohms ohms ohms FLR190F 1.9 3.9 15 100 1.2 0.039 0.072 0.102 FLR260F 2.6 5.8 15 100 2.5 0.020 0.042 0.063 FLR380F 3.8 8.3 15 100 2.5 0.013 0.026 0.037 FLR450F 4.5 8.9 20 100 2.5 0.011 0.020 0.028 FLR550F 5.5 10.5 20 100 2.8 0.009 0.016 0.022 FLR600F 6.0 11.7 20 100 2.8 0.007 0.014 0.019 FLR730F 7.3 14.1 20 100 3.3 0.006 0.012 0.015 P/N Pcs /Bag FLR190F 2K FLR260F 2K FLR380F 2K P/N Pcs /Bag FLR450F 2K FLR550F 2K FLR600F 2K FLR730F 2K
