供应君耀陶瓷气体放电管2RM350M-8/S 2RM420M-8/S 2RM470M-8/S 2RM600M-8/S 2RM800M-8/S 2RM1000M-8/S
| 价 格： | 面议 | |
| 型号/规格： | 2RM350M-8/S 2RM420M-8/S 2RM470M-8/S 2RM600M-8/S 2RM800M-8/S 2RM1000M-8/S | |
| 品牌/商标： | 君耀 |
2RM350M-8/S 2RM420M-8/S 2RM470M-8/S 2RM600M-8/S 2RM800M-8/S 2RM1000M-8/S君耀贴片和直插陶瓷气体放电管，雷击电流10KA 尺寸8*6，一端方形一端圆形SMD封装，下面是一些基本参数，需要详细了解请来电咨询或者查看PDF规格书：
Part Number DCSpark-overVoltage MaximumCapacitance 8/20μs ImpulseDischargeVoltage
2RM350M-8/S 350±20% 900 10 2.5 10 500 100 1.0 1.5 2RM350-82RM420M-8/S 420±20% 1000 10 2.5 10 500 100 1.0 1.5 2RM420-8
2RM470M-8/S 470±20% 1000 10 2.5 10 500 250 1.0 1.5 2RM470-8
2RM600M-8/S 600±20% 1200 10 2.5 10 500 250 1.0 1.5 2RM600-8
2RM800M-8/S 800±20% 1400 10 2.5 10 500 250 1.0 1.5 2RM800-8
2RM1000M-8/S 1000±20% 1700 10 2.5 10 500 250 1.0 1.5 2RM1000-8
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杨先生
- 电话：0755-32826987
- 传真：0755-23221987
- 手机：18926016675
- QQ ：
供应君耀陶瓷气体放电管2RM075M-8/S 2RM090M-8/S 2RM150M-8/S 2RM230M-8/S 2RM250M-8/S 2RM300M-8/S
信息内容：2RM075M-8S 2RM090M-8S 2RM150M-8S 2RM230M-8S 2RM250M-8S 2RM300M-8S 2RM350M-8S为君耀贴片和直插陶瓷气体放电管，雷击电流10KA 尺寸8*6，一端方形一端圆形SMD封装，下面是一些基本参数，需要详细了解请来电咨询或者查看PDF规格书： Part Number DCSpark-overVoltage MaximumCapacitance 8/20μs ImpulseDischargeVoltage 2RM075M-8/S 75±20% 600 10 2.5 10 500 25 1.0 1.5 2RM075-8 2RM090M-8/S 90±20% 600 10 2.5 10 500 50 1.0 1.5 2RM090-8 2RM150M-8/S 150±20% 600 10 2.5 10 500 100 1.0 1.5 2RM150-8 2RM230M-8/S 230±20% 700 10 2.5 10 500 100 1.0 1.5 2RM230-8 2RM250M-8/S 250±20% 700 10 2.5 10 500 100 1.0 1.5 2RM250-8 2RM300M-8/S 300±20% 900 10 2.5 10 500 100 1.0 1.5 2RM300-8 2RM350M-8/S 350±20% 900 10 2.5 10 500 100 1.0 1.5 2RM350-8
供应君耀陶瓷气体放电管2RP470L-8 2RP470M-8 2RP600L-8 2RP600M-8 2RP800L-8 2RP800M-8
信息内容：2RP470L-8 2RP470M-8 2RP600L-8 2RP600M-8 2RP800L-8 2RP800M-8为君耀贴片和直插陶瓷气体放电管，雷击电流10KA 尺寸8*6，L为直插引脚 M为贴片SMD封装，下面是一些基本参数，需要详细了解请来电咨询或者查看PDF规格书： Part Number DCSpark-overVoltage MaximumCapacitance 8/20μs ImpulseDischargeVoltage 2RP470L-8 2RP470M-8 470±20% 1100 20 20 500 250 1.0 1.5 2RP470-8 2RP600L-8 2RP600M-8 600±20% 1300 20 20 500 250 1.0 1.5 2RP600-8 2RP800L-8 2RP800M-8 800±20% 1500 20 20 500 250 1.0 1.5 2RP800-8
