Spec: 2.54mm pin Header, Single Row, Straight
pins: 2p~40p
Plastics Height: 2.54mm
Materials: PBT+30%GFUL94V-0

MATERIAL

Insulator: PBT+30%GF(UL94V-O)

Contact: Brass

Contact Plating: Gold over 50u”Nickel

Color: Blue Yellow White

Plating: 0.8u”AU

SPECIFICATION

Current Rate: 3Amp

Operation Temperature: -40℃ to+105℃

Contact Resistance:20MΩMAX.at DC 1A

Insulation Resistance:1000MΩMIN.at DC500V

Withstanding Voltage: AC 500V Per minute

深圳市鹰健连电子有限公司，是一家集开发、生产、销售为一体的电子连接器制造企业。本公司拥有一批高素质技术人才，不断地引进和吸收国内外电子制造先进技术，生产设备和检测仪器来确保产品品质。 本公司自成立以来，一直秉承“全面品质管理、满足客户需求，追求卓越品质”的质量方针，和“诚信为本、客户至上”的经营理念，及“团结、拼搏、创新、发展”的企业精神。以严谨的管理、优良的品质和完善的服务赢得了国内外广大客户的信赖和合作。 公司目前主要产品有0.8mm、1.0 mm、1.27 mm、2.0 mm、2.54 mm、3.96 mm间距的各类排针、排母、简易牛角、勾勾牛角、WAFER、SATA7+15、FPC/FFC、电池座、USB等电子连接器和相应连接电子线。产品广泛应用于电脑、通讯、电源、电子、电器、数码产品、显示器、工控、仪表、机顶盒等其它电子产品。 真诚期待与广大国内外客户同行携手共进，共创辉煌。 Brief Introduction Of Company Shenzhen Ying Jian Lian electronic Co., Ltd. is a collection development, production, sales as one of professional electronic connector manufacturing enterprise. The company has a number of highly qualified technical personnel, constantly introducing and absorbing the domestic and foreign electronic manufacturing advanced technology, production equipment and testing equipment to ensure the quality of products. The company since its inception, has been adhering to the "total quality management, to meet customer demand, the pursuit of excellence quality" the quality policy, and "the good faith for this, the customer is supreme" the management idea, and "unity, hard work, innovation and development," the spirit of enterprise. With the strict management, good quality and perfect service to win the trust and cooperation of customers from domestic and abroad. The main products of our company is 0.8 mm, 1.0 mm and 1.27 mm and 2.0 mm and 2.54 mm and 3.96 mm spacing of all kinds of Pin Header, Female Header, Box header, Ejector Header, WAFER, SATA7 + 15, FPC/FFC, battery holder, USB and other electronic connector and corresponding connection electronic line. The products are widely used in computer, communication, power supply, electronics, electrical appliances, digital products, display, industrial control, instrumentation, set-top box, and other electronic products. Sincerely look forward to working with clients at home and abroad together hand in hand, and create brilliant.
