供应高品质不锈钢水流开关 流量开关
| 价 格： | 100.00 | |
| 型号/规格： | FS-1S-3-4SS | |
| 品牌/商标： | FAST |
|
Electrical Characteristics |
Units |
|
|
Material |
|
SUS304 |
|
Ring Material |
|
SUS304 |
|
Tempe Rating |
`C |
-40~+110 |
|
Max Pressure |
MPa |
2 |
|
Max Volume |
|
30L |
|
Max Contact Rating |
W |
70 |
|
Max Switching Voltage |
VDC |
≤250 (12, 24V) |
|
Max Switching Current |
A |
0.5 |
|
Max contact Resistance |
mOhm |
200 |
|
Electrical Life (at Resistance load ) |
VDC/mA |
1.5x107 (20/500) |
|
Cable Type |
|
UL1332-AWG22 |
|
Cable Length |
mm |
500 |
|
Cable Color |
|
Blue |
- 所属城市：湖北 武汉
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李建/彭新荣
- 电话：027-87565009
- 传真：027-87565009
- 手机：13613065180/13728826625
- QQ ：
供应高质量塑料水流开关 流量开关
信息内容：Electrical Characteristics Units Material NYLON Ring Material NYLON Tempe Rating `C -30~+90 Max Pressure MPa 2 Max Volume 20L Max Contact Rating W 70 Max Switching Voltage DC:6-100V AC:9-250V Max Switching Current ...
供应高性价比黄铜水流开关 流量开关
信息内容：Electrical Characteristics Units Material Cu Ring Material SUS304 Tempe Rating `C -30~+140 Max Pressure MPa 2 Max Volume 30L Max Contact Rating W 70 Max Switching Voltage VAC 250 Max Switching Current ...
