供应射频变压器 ADT1-6T+
| 价 格： | 面议 | |
| 型号/规格： | ADT1-6T+ | |
| 品牌/商标： | Mini-Circuits | |
| 包装方式： | 多件包装 | |
| 主要用途： | 精密电子仪器仪表 | |
| 适用电源类别： | 单相 | |
| 铁芯类型： | E型 | |
| 频率特征： | 中频 | |
| 导线类型： | 铜导线 |
ADT1-6T+：Mini-Circuits 射频变压器 Surface Mount RF Transformer 50Ω 0.03 to 125 MHz
Maximum Ratings
Operating Temperature -20°C to 85°C
Permanent damage may occur if any of these limits are exceeded
Pin Connections
PRIMARY DOT 3
Features
• excellent amplitude unbalance, 0.1 dB typ. and phase unbalance, 1 deg. typ. in 1dB bandwidth
Applications
• impedance matching
Storage Temperature -55°C to 100°C
RF Power 0.5W
DC Current 30mA
PRIMARY 1
SECONDARY DOT 4
SECONDARY 6
SECONARY CT 5
NOT USED 2
• excellent return loss, 18 dB typ. in 1 dB bandwidth
• aqueous washable
• protected under US patent 6,133,525
• balanced amplifier
