供应功率分配器 GP2X1+
| 价 格： | 面议 | |
| 型号/规格： | GP2X1+ | |
| 品牌/商标： | Mini-Circuits |
GP2X1+：Mini-Circuits 功率分配器 Surface Mount Power Splitter/Combiner 2 Way-0° 50Ω 2800 to 7200 MHz
Maximum Ratings
Operating Temperature -40°C to 85°C
Storage Temperature -65°C to 150°C
Power Input (as a splitter) 1.5W max.
Internal Dissipation 0.75W max.
Permanent damage may occur if any of these limits are exceeded.
Pad Connections
SUM PORT 2
PORT 1 7
PORT 2 9
GROUND 1,3,4,5,6,8,10,11,12, paddle
Features
• very wide bandwidth, 2800 to 7200 MHz
• excellent amplitude unbalance, 0.1 dB typ.
• good phase unbalance, 3 deg. typ.
• small size, 0.118”x0.118”x0.035”
• high ESD level
• aqueous washable
Applications
• WIMAX
• WLAN
• radar
• satellite communication
• ISM
• instrumentation
我公司经营惠普（HP）、安捷伦（AGI）,AVG,Sirenza,Mini、HITTITE、M/A-COM等半导体一系列产品，并常备大量现货库存特价供应。如高频高增益低噪声镓砷化物FET管、高频低噪声硅双极MMIC、RFK扩音放大器。高频硅双极MMIC混音器，高频低噪声硅双极晶体管。HP/Agilent光电耦合器全系列,数据传输线,光电,光纤传输系列。本公司随时拥有的手讯息，以的服务，惠的价格，最快的速度，给您提供质的产品。Mini-Circuits：主要产品Mini-Circuits产品类别丰富，广泛应用于各种无线通信、有线电视、工业控制、医疗电子、航空雷达等领域。小批量研制到规模化生产灵活的产品策略满足客户各种特殊要求，全方位的技术服务为目前的无线数据通信产业客户提供先进的产品。
备注：本司长期现货供应型号：
MAR-1+ MAR-1SM+ MAR-2SM+ MAR-3+ MAR-3SM+ MAR-4+ MAR-4SM+ MAR-6+ MAR-6SM+ MAR-7SM+ MAR-8A+ MAR-8ASM+ MAR-8SM+ MAV-11BSM+ MAV-11SM+ MAX-9H MAX-19H MBA-10L MBA-12 MBA-15L MBA-15LH MBA-15MH MBA-18LH MBA-25L MBA-25LH MBA-25MH MBA-591 MBA-591L MBA-671 MCA-19FH MCA-19FLH MCA-19FMH+ MCA-30FH+ MCA-30FLH MCA-30FMH MCA-35H+ MCA-35LH+ MCA-35MH+ MCA-36FH MCA-36FLH MCA-36FMH MCA-50H+ MCA-50LH+ MCA-50MH+ MCA1-12G+ MCA1-12GL+ MCA1-24+ MCA1-24LH+ MCA1-24MH+ MCA1-42+ MCA1-42LH+ MCA1-42MH+ MCA1-60+ MCA1-60LH+ MCA1-60MH+ MCA1-80H+ MCA1-80LH+ MCA1-80MH+ MCA1-85+ MCA1-85L+ MCA1-113H+ MERA-533+ MERA-556+ MERA-7433+ MERA-7456+ MIQA-10D MIQA-10M MIQA-21D MIQA-21M MIQA-70D MIQA-70M MIQA-70ML MIQA-91M MIQA-100M MIQA-195M MIQC-60WD MIQC-88M MIQC-176M MIQC-895M MIQC-1785M MIQC-1880M MIQY-70D MIQY-70M MIQY-140D MIQY-140M MK-2 MK-3 MK-5 MNA-2 MNA-3 MNA-4+ MNA-5+ MNA-6+ MNA-7+ MOS-114+ MOS-810-119+ MOS-1400-119+ MOS-1632-119+ MOS-1739-219+ MOS-1826PV+ MOS-1890-119+ MOS-2033-119+ MOS-2133-219+ MOS-2220-119+ MPD-1+ MPD-2+ MPD-21+ MSC-2-1+ MSC-2-1W MSC-2-5 MSC-2-11 MSC-3-1W MSP2T-18 MSP2TA-18 MSW-2-20 MSWA-2-20 MSWT-4-20 MTS-18B MVA-1000+ MVA-2000+ NAT-3DC+ NAT-3DC-1A+ GP2S+,GP2S1+,GP2X+,GP2X1+,GP2Y+,GP2Y1+...
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
