供应Mini-Circuits低通滤波器 LFCN-630+
| 价 格： | 面议 | |
| 型号/规格： | LFCN-630+ | |
| 品牌/商标： | Mini-Circuits |
LFCN-630+：Mini-Circuits 陶瓷低通滤波器 Ceramic Low Pass Filter 50Ω DC(1) to 630 MHz
Maximum Ratings
Operating Temperature -55°C to 100°C
Storage Temperature -55°C to 100°C
RF Power Input* 8.5W max. at 25°C
* Passband rating, derate linearly to 3.5W at 100°C ambient.Permanent damage may occur if any of these limits are exceeded
Pin Connections
RF IN 1
RF OUT 3
GROUND 2,4
Features
• excellent power handling, 8.5W
• small size
• 7 sections
• temperature stable
• LTCC construction
• protected by U.S. Patent 6,943,646
Applications
• harmonic rejection
• VHF/UHF transmitters/receivers
• RF suppression for DC lines on PCB
• anti-aliasing for A/D converter
