供应射频变压器 TC1-1TG2
| 价 格： | 面议 | |
| 型号/规格： | TC1-1TG2 | |
| 品牌/商标： | Mini-Circuits |
TC1-1TG2+：Mini-Circuits RF射频变压器 Surface Mount RF Transformer 50Ω 0.4 to 500 MHz
Maximum Ratings
Operating Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
RF Power 0.25W
DC Current 30mA
Permanent damage may occur if any of these limits are exceeded
Pin Connections
PRIMARY DOT 6
PRIMARY 4
SECONDARY DOT 1
SECONDARY 3
SECONDARY CT 2
Features
• suitable for tin/lead and RoHS solder systems
• usable over 0.4-500 MHz
• excellent amplitude unbalance, 0.1 dB typ.and phase unbalance, 2 deg typ. in 1 dB bandwidth
• good return loss
• aqueous washable
Applications
• VHF/UHF receivers/transmitters
• push-pull amplifiers
浩时健欢迎国外高科技微波、光纤厂商将产品介绍到中国、共同开拓市场。长期大量现货批发高频、微波、卫星、光纤、电视、CATV器件: 晶振、VCO、连接器、PIN开关、变容二极管、开关二极管、低噪晶体管、功率电阻及电容、放大器、功率管、MMIC、混频器、耦合器、功分器、振荡器、合成器、衰减器、滤波器、隔离器、环行器、移相器、调制解调器；光电子元器件和组件：红外发射管、红外接收管、光电开关、光敏管、发光二极管和发光二极管组件、半导体激光二极管和激光器组件、光电探测器和光接收组件、光发射接收模块、光纤激光器和光放大器、光调制器、光开关、DWDM用光发射和接收器件、用户接入系统光光收发器件与模块、光纤连接器、光纤跳线/尾纤、光衰减器、光纤适 配器、光隔离器、光耦合器、光环行器、光复用器/转换器；无线收发芯片和模组、蓝牙芯片和模组。MRFXX、三菱MOTOROLA、爱立信、ASI、富士通等军民用射频产品。惠普Hp、安捷伦Agilent全系列高频放大管，微波集成电路IC，混频管，PIN管，肖特基管，MMIC，HEMT等元器件。可能是惠普Hp 安捷伦Agilent全系列产品现货最多，品类最全，价格的一家。一级代理Mini-Circuits产品类别丰富，广泛应用于各种无线通信、有线电视、工业控制、医疗电子、航空雷达等领域。小批量研制到规模化生产灵活的产品策略满足客户各种特殊要求，全方位的技术服务为目前的无线数据通信产业客户提供先进的产品。
备注：本司长期现货供应型号：
LAT-0+ LAT-1+ LAT-2+ LAT-3+ LAT-4+ LAT-5+ LAT-6+ LAT-7+ LAT-8+ LAT-9+ LAT-10+ LAT-12+ LAT-15+ LAT-20+ LAT-30+ LAVI-2VH+ LAVI-9VH+ LAVI-10VH+ LAVI-17VH+ LAVI-22VH+ LAVI-23VH+ LAVI-25VH+ LAVI-252H+ LAVI-252VH+ LAVI-362VH+ LAVI-711H+ LAVI-971VH+ LAVI-U252VH+ LAVI-U182H+ LEE-19+ LEE-29+ LEE-39+ LEE-49+ LEE-59+ LFCN-80D LFCN-80 LFCN-95 LFCN-95D LFCN-105 LFCN-105D LFCN-120D LFCN-120 LFCN-160+ LFCN-160D+ LFCN-180 LFCN-180D LFCN-190+ LFCN-190D+ LFCN-225D+ LFCN-225 LFCN-320D+ LFCN-320 LFCN-400D+ LFCN-400 LFCN-490D+ LFCN-490 LFCN-530 LFCN-530D+ LFCN-575D LFCN-575 LFCN-630 LFCN-630D LFCN-800D LFCN-800 LFCN-900 LFCN-900D LFCN-1000D LFCN-1000 LFCN-1200D LFCN-1200 LFCN-1325 LFCN-1325D LFCN-1400D LFCN-1400 LFCN-1450 LFCN-1450D LFCN-1500 LFCN-1500D LFCN-1525D LFCN-1525 LFCN-1575 LFCN-1575D LFCN-1700D LFCN-1700 LFCN-1800D LFCN-1800 LFCN-2000 LFCN-2000D LFCN-2250 LFCN-2250D LFCN-2400D LFCN-2400 LFCN-2500D LFCN-2500 LFCN-2600 LFCN-2600D LFCN-2750 LFCN-2750D LFCN-2850 LFCN-2850D LFCN-3000 LFCN-3000D LFCN-3800D LFCN-3800 LFCN-4400 LFCN-4400D LFCN-5000 LFCN-5000D LFCN-5500+ LFCN-5500D+ LFCN-5850+ LFCN-5850D+ LFCN-6000 LFCN-6000D LFCN-6400+ LFCN-6400D+ LFCN-6700 LFCN-6700D LFCN-7200+ LFCN-7200D+ LFTC-850+ LFTC-1350 LFTC-1350+ LFTC-1700+ LFTC-1700 LFTC-2000 LFTC-2000+ LFTC-3300+ TC1-1TG2+,TC1-1-13M+,TC1-1-13M-22+,TC1-1-13M-23，TC1-1-13M-75+,TC1-1-13M-75X+,TC1-1-13MA+,TC1-1-13MG2+,TC1-1-13MX+...
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
供应射频变压器 TC1.5-1+
信息内容：TC1.5-1+：Mini-Circuits RF变压器 Surface Mount RF Transformer 50Ω 0.5 to 2200 MHz Maximum Ratings Operating Temperature -20°C to 85°C Storage Temperature -55°C to 100°C RF Power 0.25W DC Current 30mA Permanent damage may occur if any of these limits are exceeded Pin Connections PRIMARY DOT 6 PRIMARY 4 SECONDARY DOT 1 SECONDARY 4 NOT USED 2,3 Features • wideband, 0.5-2200 MHz, • excellent return loss • terminations, solder plated with nickel barrier for solderability & excellent each resistance • autotransformer • plastic base with leads • aqueous washable Applications • impedance matching 浩时健电子主要代理美国、欧洲等微波器件厂商在亚太地区的推广销售，致力于向国内客户，尤其是为从事航天、航空、雷达、电子对抗、卫星通讯、短波通信、跳频电台等各大科研院所、生产厂家提供...
供应射频变压器 TC1-1-13MA+
信息内容：TC1-1-13M：Mini-Circuits RF射频变压器 Surface Mount RF Transformer 50Ω 4.5 to 3000 MHz Maximum Ratings Operating Temperature -40°C to 85°C Storage Temperature -55°C to 100°C RF Power 0.25W DC Current 30mA Permanent damage may occur if any of these limits are exceeded Pin Connections PRIMARY DOT 6 PRIMARY 4 SECONDARY DOT 1 SECONDARY 3 NOT USED 2 Features • wideband, 4.5 to 3000 MHz • balanced transmission line • good return loss • excellent amplitude unbalance, 0.5 dB typ. and phase unbalance, 2 deg typ. in 1 dB bandwidth • plastic base with leads • aqueous washable Applications • balanced to unbalanced transformation • push-pull amplifiers • PCS/DCS • MMDS 浩时健电子主要产品有：限幅器系列、微波开关系列、微波开关矩阵系列、电调衰减器系列、可编程...
