供应射频变压器 TT1.5-1-X65+
| 价 格： | 面议 | |
| 型号/规格： | TT1.5-1-X65+ | |
| 品牌/商标： | Mini-Circuits |
TT1.5-1-X65+：Mini-Circuits 射频变压器 Plug-In RF Transformer 50Ω 0.075 to 500 MHz
Maximum Ratings
Operating Temperature -20°C to 85°C
Storage Temperature 55°C to 100°C
RF Power 250mW
DC Current 30mA
Permanent damage may occur if any of these limits are exceeded.
Pin Connections
PRIMARY DOT 4
PRIMARY 6
PRIMARY CT 5
SECONDARY DOT 3
SECONDARY 1
SECONDARY CT 2
Features
• wideband, 0.075 to 500 MHz
• also available with flat-pack (W38) & surface mount gull-wing (KK81) leads
• good return loss
Applications
• VHF/UHF
• impedance matching
• CATV
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
