供应功率分配器 JPS-2-1+
| 价 格： | 面议 | |
| 型号/规格： | JPS-2-1+ | |
| 品牌/商标： | Mini-Circuits |
JPS-2-1+：Mini-Circuits 功率分配器 Surface Mount Power Splitter/Combiner 2 Way-0° 50Ω 1 to 500 MHz
Maximum Ratings
Operating Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
Power Input (as a splitter) 1W max.
Internal Dissipation 0.125W max.
Permanent damage may occur if any of these limits are exceeded.
Pin Connections
SUM PORT 1
PORT 1 3
PORT 2 4
GROUND 6
NOT USED 2,5
Features
• low insertion loss, 0.25 dB typ.
• excellent insertion loss flatness, 0.3 dB peak to peak
• excellent amplitude unbalance, 0.1 dB typ.
• very good phase unbalance, 0.1 deg. typ.
• J-leads for excellent solderability and strain relief
Applications
• VHF receivers/transmitters
• instrumentation
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
