PAT-15+：微型陶瓷固定衰减器  50欧 1W 15dB  DC to 7000 MHz

Maximum Ratings（额定值）：

Operating Temperature 工作温度   -55°C to 100°C

Storage Temperature   存储温度   -55°C to 100°C

Pin Connections：

● INPUT 1

● OUTPUT 3

● GROUND 2,4

Features：

● wideband, DC to 7000 MHz

● excellent VSWR, through entire band

● miniature size

● aqueous washable

Applications：

● power leveling

● impedance match improvement
