供应射频变压器 ADTT1-1+
| 价 格： | 面议 | |
| 型号/规格： | ADTT1-1+ | |
| 品牌/商标： | Mini-Circuits |
ADTT1-1+：Mini-Circuits 射频变压器 Surface Mount RF Transformer 50Ω 0.3 to 300 MHz
Maximum Ratings
Operating Temperature -20°C to 85°C
Storage Temperature -55°C to 100°C
RF Power 0.25W
DC Current 30mA
Permanent damage may occur if any of these limits are exceeded
Pin Connections
PRIMARY DOT 3
PRIMARY 1
PRIMARY CT 2
SECONDARY DOT 4
SECONDARY 6
SECONDARY CT 5
Features
• good return loss, 18 dB in 1 dB bandwidth
• excellent amplitude unbalance, 0.15 dB typ. and phase unbalance, 1 deg. typ. in 1 dB bandwidth
• aqueous washable
• protected under U.S. Patent 6,133,525
Applications
• impedance matching
• baluns
Mini-Circuits：主要产品
混频器、功分器/合路器、阻抗变换器、衰减器、匹配负载、变压器、电缆、转接头、隔直模块、 功率检波器、放大器、调制器/解调器、定向耦合器、相位检波器、线延伸器、限幅器、倍频器、压控振荡器、偏置器、扼流圈、移相器、滤波器、开关。
Mini-Circuits产品类别丰富，广泛应用于各种无线通信、有线电视、工业控制、医疗电子、航空雷达等领域。小批量研制到规模化生产灵活的产品策略满足客户各种特殊要求，全方位的技术服务为目前的无线数据通信产业客户提供先进的产品。
备注：本司长期现货供应型号：
ADT1-1+,ADT1-1WT+,ADT1-1WT-1+,ADT1-6T+,ADT1.5-1+,ADT1.5-122+,ADT1.5-17+,ADT1.5-2+,ADT16-1T+,ADT16-6+,ADT16-6T+,ADT2-1T+,ADT3-1T+,ADT3-6T+,ADT4-1T+,ADT4-6+,ADT-6T+,ADT4-6WT+,ADT8-1T+,ADT9-1T+,ADTL1-12+,ADTL1-15-75+,ADTL2-18+,ADTT1-1+,ADTT1-6+,ADTT1.5-1+,ADTT3-2+,ADTT4-1+...
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
