供应EPCOS放电管FS08X-1GH B88069X0340xxxx
| 价 格： | 面议 | |
| 型号/规格： | FS08X-1GH B88069X0340xxxx | |
| 品牌/商标： | EPCOS |
FS08X-1GH B88069X0340xxxx为EPCOS开关放电管，二极带引线直插系列，直径8mm宽7.9mm；下面部分参数，详细请参阅PDF或者来电咨询：
Nominal breakdown voltage VN 800V
Initial valuesStatic breakdown voltage VS
First ignition value VS, FTE after 24 hours in darkness ≤ 460V
Following ignition values (selection limits) 360 ... 420V
Following ignition values VS, FIV 350 ... 430 V
Breakdown voltage VB (measuring time 200 ms)
First ignition value VB, FTE ≤ 460V
Following ignition values V 340 ... 460 V
Marking, blue EPCOS 800 WWY O
WW - Calendar week of productio
Y - Year of production
O - Non radioactive
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杨先生
- 电话：0755-32826987
- 传真：0755-23221987
- 手机：18926016675
- QQ ：
供应EPCOS放电管FS04X-1JMG B88069X0410T502
信息内容：FS04X-1JMG B88069X0410T502为EPCOS开关放电管，二极带引线直插系列，直径8mm宽7.9mm；下面部分参数，详细请参阅PDF或者来电咨询： Nominal breakdown voltage VN 400V Initial values Static breakdown voltage VS First ignition value VS, FTE after 24 hours in darkness ≤ 460V Following ignition values (selection limits) 360 ... 420V Following ignition values VS, FIV 350 ... 430 V Breakdown voltage VB (measuring time 200 ms) First ignition value VB, FTE ≤ 460V Following ignition values V 340 ... 460 V Marking, blue EPCOS 400 WWY O WW - Calendar week of productio Y - Year of production O - Non radioactive
供应EPCOS放电管SSG5X-1 B88069X0270S102
信息内容：SSG5X-1 B88069X0270S102为EPCOS开关放电管，两极引线直插，直径8mm宽6mm，下面是常见参数，如有疑问可以参见PDF文档或者来电咨询： Nominal breakdown voltage VN 5000 V Initial values Static breakdown voltage V First ignition value V after 24 hours in darkness ≤ 2600V Following ignition values V 1600 ... 2400V General technical data Insulation resistance at 100 V > 100MΩ Early ignition values 1000 ... 1600 V ≤ 3% Breakdown tim ≤ 50ns Weight ~ 2g Marking, red EPCOS 5000 YY O YY - Year of production O - Non radioactive
