供应EPCOS放电管SSG3X-1 B88069X0260S102
| 价 格： | 面议 | |
| 型号/规格： | SSG3X-1 B88069X0260S102 | |
| 品牌/商标： | EPCOS |
SSG3X-1 B88069X0260S102为EPCOS开关放电管，两极引线直插，直径8mm宽6mm，下面是常见参数，如有疑问可以参见PDF文档或者来电咨询：
Nominal breakdown voltage VN 3000 V
Initial values
Static breakdown voltage V
First ignition value V after 24 hours in darkness ≤ 2600V
Following ignition values V 1600 ... 2400V
General technical data
Insulation resistance at 100 V > 100MΩ
Early ignition values 1000 ... 1600 V ≤ 3%
Breakdown tim ≤ 50ns
Weight ~ 2g
Marking, red EPCOS 3000 YY O
YY - Year of production
O - Non radioactive
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杨先生
- 电话：0755-32826987
- 传真：0755-23221987
- 手机：18926016675
- QQ ：
供应EPCOS放电管SSG03X-1J B88069X6331****
信息内容：SSG03X-1J B88069X6331****为EPCOS开关放电管，两极引线直插，直径8mm宽6mm，下面是常见参数，如有疑问可以参见PDF文档或者来电咨询： Nominal breakdown voltage VN 350 V Initial values Static breakdown voltage V First ignition value V after 24 hours in darkness ≤ 2600V Following ignition values V 1600 ... 2400V General technical data Insulation resistance at 100 V > 100MΩ Early ignition values 1000 ... 1600 V ≤ 3% Breakdown tim ≤ 50ns Weight ~ 2g Marking, red EPCOS 350 YY O YY - Year of production O - Non radioactive
供应EPCOS放电管SSG03X-1G B88069X0220T502
信息内容：SSG03X-1G B88069X0220T502为EPCOS开关放电管，两极引线直插，直径8mm宽6mm，下面是常见参数，如有疑问可以参见PDF文档或者来电咨询： Nominal breakdown voltage VN 350V Initial values Static breakdown voltage V First ignition value V after 24 hours in darkness ≤ 2600V Following ignition values V 1600 ... 2400V General technical data Insulation resistance at 100 V > 100MΩ Early ignition values 1000 ... 1600 V ≤ 3% Breakdown tim ≤ 50ns Weight ~ 2g Marking, red EPCOS 350 YY O YY - Year of production O - Non radioactive
