供应EPCOS压敏电阻B72220Q 171K101 Q20K175
| 价 格： | 面议 | |
| 型号/规格： | B72220Q 171K101 Q20K175 | |
| 品牌/商标： | EPCOS | |
| 环保类别： | 无铅环保型 |
B72220Q 171K101 Q20K175
Leaded varistors B722*EnergetiQ series
Construction
Square varistor element, leaded
Coating: epoxy resin, flame-retardant to UL 94 V-0
Features
High-EnergetiQ series Q14/Q20
Maximum load capacity at minimum component height
Very high surge current ratings up to 15 kA
All types duty cycle @ 6 kV/ 3 kA → 10 pulses, according to IEC 60950-1 Annex Q;
IEC 61051-2
All types I
nom
@ 3 kA (Q14), I
nom
= 5 kA (Q20) → 15 impulses according to UL 1449, 3
edition surge current generator (8/20 µs), Type 2 listed
PSpice models
Approvals
UL
CSA
VDE
IEC
Delivery mode
Bulk (standard), taped versions on reel or in Ammo pack upon request.
For further details refer chapter "Taping, packaging and lead configuration" for leaded
varistors.
General technical data
Climatic category to IEC 60068-1 40/85/56
Operating temperature to IEC 61051 40 ... + 85 °C
Storage temperature 40 ... +125 °C
Electric strength to IEC 61051 ≥ 2.5 kV
Insulation resistance to IEC 61051 ≥ 100 MΩ
Response time < 25 ns
rd
RMS
