供应EPCOS放电管EM300X B88069X0800
| 价 格： | 面议 | |
| 型号/规格： | EM300X B88069X0800 | |
| 品牌/商标： | EPCOS |
Surge arrester B88069X0800xxxx
2-electrode arrester EM300X
Features Applications
Very small size
Fast response time
Stable performance over life
Extremely low capacitance
High insulation resistance
RoHS-compatible
Electrical specifications
DC spark-over voltage
1) 2)
Modem
XDSL-splitter
Tuner
270 ... 345 V
Impulse spark-over voltage
at 100 V/µs - for 99 % of measured values
- typical values of distribution
at 1 kV/µs - for 99 % of measured values
- typical values of distribution
< 700
< 600
< 800
< 700
Service life
10 operations 50 Hz, 1 s 2.5 A
10 operations 8/20 µs 2.5 kA
1 operation 10/350 µs 0.5 kA
> 1
GΩ
Capacitance at 1 MHz < 1 pF
Arc voltage at 1 A
Insulation resistance at 100 V
Glow to arc transition current
Glow voltage
dc
~ 11
~ 0.5
~ 80
Weight ~ 1 g
Operation and storage temperature -40 ... +90 °C
Climatic category (IEC 60068-1) 40/ 90/21
Marking, red positive
a)
xxxx = S102 (100 pcs on 5 taped stripes)
= T502 (500 pcs on tape and reel)
1)
2)
At delivery AQL 0.65 level II, DIN ISO 2859
In ionized mode
Terms in accordance with ITU-T Rec. K.12 and DIN 57845/VDE0845
EM 300 YY O
EM - Series
300 - Nominal voltage
YY - Year of production
O - Non radioactive
V
V
V
V
V
A
V
a)
