尺寸(mm)长X宽X高 :23.x16.1x10.2
特性 :SPST-5A
触点形式:LOW Profile PCBoard Sensitive coil 200mA
触点材料:10A 250VDC/15A 125VAC/10A 24VDC
额定通断电流:110VDC
通断电压: 250VDC
最小通断电流:15A
通断功率:2.500VA 240W
最小通断电流及电压:5VDC 100A
触点接触电电阻(首次):50
线圈电压：3-48VDC
线圈功耗:200
介质耐压触点间线圈和触点:750V
线圈和触点: 2,500V
绝缘电阻:1000
寿命(次)Life :100,000
电寿命:10,000,000
机械寿命
工作环境卫生 温度范围:-30- 70℃
吸合时间:15ms
释放时间:8ms
试水结构:-
脚位形式:P.C.B,Quick
重量:V6:9 V6F:10 |
Dimension(mm)LxWxH:23.x16.1x10.2
Feature:SPST-5A
Contact form:LOW Profile PCBoard Sensitive coil 200mA
Contact Material:10A 250VDC/15A 125VAC/10A 24VDC
Rated Switching Current:110VDC
Max.Switching Voltage:250VDC
Max.Switching Current:15A
Max.Switching Power:2.500VA 240W
Min Switching Current & Voltage:5VDC 100A
Contact Resistance(Initial)
mΩ at 6VDC 1A:50
Coil Voltage:3-48VDC
Coil Power Consumption(mW):200
Dielectric Strength:750V
Between Contacts:2,500V
Insulation Resistance
MΩ(at 500VDC):1000
Life Expectancy(ops.):100,000
Electrical::10,000,000
Mechtrical:Operation temp.Range::-30- 70℃
Operation temp:15ms
Release time:8ms
Structure :-
teminal shape:P.C.B,Quick
Weight(g):V6:9 V6F:10
