Apem2小型钮子开关型号3647MF/2进口钮子开关UL认证钮子开关IP67防水钮子开关
上海APEM代理商 APEM代理 021-36588205 36588207 北京APEM代理 广东省 深圳 江苏省 无锡APEM 天津APEM
进口钮子开关价格查询全国统一热线4006-022-002 Apem钮子开关报价
法国品牌APEM中国代理商提供Apem开关选型手册pdf说明书样本
authorized Apem distributor China
中国区获奖代理商
单极钮子开关；双极钮子开关；
12A 28VDC - 6A 250VAC
电气寿命: 全负载时10000次；
工作温度： -40°C to +85°C
双极钮子开关型号: 螺丝端子钮子开关型号:
3641NF ON - OFF
3644NF* ON ON ON
3645NF MOM - ON
3646NF ON - ON
3647NF MOM OFF MOM
3648NF ON OFF MOM
3649NF ON OFF ON
3647NF； 6个螺丝固定脚,自动复位,APEM5 IP67防水摇头开关
3637NF； 3个螺丝固定脚,自动复位,APEM5 IP67防水摇杆开关
3647MF/2
3649NF/2






 Available in 1 and 2 pole configurations with solder lug, quick connect or screw terminals. Solid silver contacts, O-ring seal, molded–in terminals, 12 amp rating, UL approval on select models, numerous electrical configurations.
- O-ring between lever and bushing
- half-length boot and nylon washer (supplied mounted)
- elastomer gasket between cover and case
- molded-in terminal inserts
  Max. current/voltage rating with resistive load : 12A 28VDC - 6A 250VAC
  Initial contact resistance : 10 mΩ max.
  Insulation resistance : 1.000 MΩ min. at 500VDC
  Dielectric strength :
2.500 Vrms 50 Hz min. between terminals
3.000 Vrms 50 Hz min. between terminals and frame
  Electrical life : 10.000 cycles at full load
Screw terminals - single pole:
3631NF; ON - OFF
3635NF; MOM - ON
3636NF; ON - ON
3637NF; MOM OFF MOM
3638NF; ON OFF MOM
3639NF; ON OFF ON
Screw terminals - double pole:
3641NF ON - OFF
3644NF* ON ON ON
3645NF MOM - ON
3646NF ON - ON
3647NF MOM OFF MOM
3648NF ON OFF MOM
3649NF ON OFF ON


Solder lug/ quick-connect terminals - single pole
3631NF/2 ON - OFF
3635NF/2 MOM - ON
3636NF/2 ON - ON
3637NF/2 MOM OFF MOM
3638NF/2 ON OFF MOM
3639NF/2 ON OFF ON


Solder lug and quick-connect terminals - double pole
3641NF/2 ON - OFF
3644NF/2* ON ON ON
3645NF/2 MOM - ON
3646NF/2 ON - ON
3647NF/2 MOM OFF MOM
3648NF/2 ON OFF MOM
3649NF/2 ON OFF ON
