Apem开关APEM翘板开关FMSeries进口船型开关FMC92A2900000翘板开关VDE认证船型开关
上海APEM代理商 APEM代理
法国Apem大船型开关型号FMSeries电源翘板开关rocker switch说明书
进口翘板开关价格查询热线4006-022-002 全国统一热线
北京船型开关；上海船型开关；深圳船型开关；无锡船型开关；天津船型开关。
6A250VAC密封船型开关 Sealed rocker switch防水翘板开关pdf选型样本


APEM1船型开关接法APEM2三档船型开关APEM3船型开关选型APEM4白色船型开关
APEM5船型按钮开关 APEM船型开关APEM6船型电源开关
APEM7双刀双掷船型开关APEM8带灯船型开关
大翘板开关，大船型开关接线图，
适用于船用，工程机械设备, 农机。
有单极翘板开关和双极船型开关,
焊接端子，快接插头连接，螺丝端子，带灯翘板开关。
使用寿命10000次
工作温度: -20°C to +85°C


















Apem rocker switch Apem Switch FMSeries
FMSeries 6A250VAC
? Approved ratings (functions 1 and 6 ) :
VDE : 10(4)A 250VAC T85°C - UL : 6A 250VAC & 125VAC T65°C
? Max. contact rating :
- functions 1 and 6 : see above.
- function 3 : 4A 250VAC
- functions 8 and 9 : 6A 250VAC
? Initial contact resistance : 20mΩ max.
? Insulation resistance : 1.000 MΩ min. at 500VDC
? Dielectric strength : - functions 1 and 6 : 2.500 Vrms between terminals
- functions 3, 8 and 9 : 1.500 Vrms between terminals
? Electrical life at full load : 10000 cycles
Operating temperature : -20°C to +85°C


Single pole rocker switches, illuminated or non-illuminated
with solder lug, quick connect or pc terminals.
Rated up to 10 amps. Numerous actuator colors.
 For class II appliances
 VDE and UL approved
 Protection against moisture by double-shell case
When the switch is submitted to moisture (drops, condensation),
the double-shell case conducts the liquid outside, thus protecting the contact area and terminals.
The light dripping inside the equipment resulting from this should be evacuated by adequate arrangement on back of panel.


 Protection by boot


In case of sand or splashing water, the best protection consists of
insulating the rocker from these aggressive elements.
This can be achieved with transparent PVC boot U5720.
Order separately, see Sealing Boot section.
