价 格: | 面议 | |
型号/规格: | AV030003A940,AV1630C9,AV0611A2AV090003A9 | |
品牌/商标: | APEM |
金属按钮开关图片进口按钮开关型号AV0630C910法国APEM开关16mm安全按钮开关
上海授权代理 广东省 深圳 江苏省 无锡 天津APEM代理商上海APEM
进口防水按钮开关价格查询全国热线4006-022-002 安全按钮开关型号
APEM代理商提供Apem开关选型手册pdf说明书样本
authorized Apem distributor
China 中国区获奖代理商
小型按钮开关
美观,坚固耐用,防爆开关,防爆按键开关。
安全按钮开关 自锁按钮开关,复位按钮开关
额定电流,额定电压 200mA 48VDC ;100mA 48VDC ;
电气寿命: 50000次,200mA 48VDC ;
100000次,100mA 48VDC ;
工作温度: -30°C to +70°C
包装: 60个
法国APEM按钮开关型号:
AVO630C910; AVO730C910; AVI630C910; AVO830C910;
AV0630C910; AV0730C910; AV1630C910; AV0830C910;
AV6P30C910; AV6B30C910;
AVO63OC910; AVO73OC910; AVI63OC910; AVO83OC910;
AV063OC910; AV073OC910; AV163OC910; AV083OC910;
AV6P3OC910; AV6B3OC910;
? Travel : 0,7 mm (.027) ± 0,1 mm (.003)
? Max. current/voltage rating with resistive load : 50mA 24VDC
? LED voltage and consumption : 2-colour LED : 2V (3V max.) 20mA
Other colours : 2V (3V max.) 10mA
(a resistor must be series-connected by the user)**
? Initial contact resistance : 100 mΩ max.
? Insulation resistance : 1.000 MΩ min. at 500VDC
? Dielectric strength : 500 Vrms 50 Hz min. between terminals
2.000 Vrms 50 Hz min. between terminals and frame
? Electrical life : 1.000.000 cycles at full load
? Operating force : 7 N ±2N
? Torque : 5 Nm min.- 14 Nm max. applied to nut
? Panel thickness : 1 (.039) to 6 mm (.236) max.
? Operating temperature : -30°C to +70°C
? Hand soldering : 270°C, 3 sec. max.
? Packaging unit : 16 pieces
** Resistor value = supply voltage - LED forward voltage
LED forward current
进口按钮开关型号AV24LP金属按钮开关图片24mm防破坏按钮开关进口按键开关型号AV24LP402 上海APEM代理商 APEM代理 北京授权代理 广东省 深圳 江苏省 无锡 查询热线4006-022-002 代理商提供Apem开关选型手册pdf说明书样本 authorized Apem distributor 北京代理商 China 中国区获奖代理商 小型按钮开关 美观,坚固耐用,防爆开关,防爆按键开关。 安全按钮开关 自锁按钮开关,复位按钮开关 镀镍, IP65按钮开关可选。 额定电流,额定电压 5A 250VAC 电气寿命: 1000000次, 1A 250VAC时 100000 次,满负载时 工作温度: -20°C to +55°C 机械寿命: 3000000次 包装: 20个(镀铬发黑的是16个) Apem2 24 mm dia. security pushbutton switches These pushbutton switches are part of the AV range of attractive, robust and durable, available with different bushing diameters, actuator shapes, bushing and actuator materials. Anti-vandal or security models. Sealing up to IP67. 产品特色 These pushbutton switches are part of the AV range of attractive, robust and durable, available with different bu...
金属按钮开关图片22mm进口按钮开关型号AV22LC402不锈钢开关IK10防破坏按钮开关防破坏按键开关型号 上海APEM代理商 APEM代理 北京授权代理 广东省 深圳 江苏省 无锡 查询热线4006-022-002 代理商提供Apem开关选型手册pdf说明书样本 authorized Apem distributor 北京代理商 China 中国区获奖代理商 小型按钮开关 美观,坚固耐用,防爆开关,防爆按键开关。 安全按钮开关 自锁按钮开关,复位按钮开关 镀镍, IP65按钮开关可选。 额定电流,额定电压 5A 250VAC 电气寿命: 1000000次, 1A 250VAC时 100000 次,满负载时 工作温度: -20°C to +55°C 机械寿命: 3000000次 包装: 20个(镀铬发黑的是16个) Max. current/voltage rating with resistive load : - A contacts : 4A 12VDC, 500.000 cycles - C contacts : 2A 48 VDC, 10.000 cycles Approved ratings of models with long case and A contacts (AV..000) : UL-CSA : 4A 250VAC - 8A 125VAC - 6.000 cycles Initial contact resistance : 10 mΩ max. Insulation resistance : 1.000 MΩ min. at 500VDC Dielectric strength : 2.000 Vrms 50 Hz min. b...
